Summary of Contents for Hawkins HWT
- Page 1 HWT Toolbar OWNER’s Manual Revised 01.20 308.708.8185 | Hawkins@HawkinsAg.com | Manual Part Number - 123010 | Rev. 01/20...
- Page 2 4. Familiarize yourself with the equipment and its operation. 5. Familiarize yourself with maintenance processes and schedules. 6. Ensure all hardware is tight and each grease zerk is greased. 7. Review all accessories, options and repair parts. Always replace parts with Hawkins Ag parts only. Delivery Date...
-
Page 3: Table Of Contents
Table of Contents General Information HOW TO USE THIS MANUAL 1 WARRANTY INFORMATION 2 SAFETY 3 SIGNAL WORDS 3... -
Page 5: How To Use This Manual 1
Part Number Index. The remaining sections divide the machine into assemblies and sub-assemblies which illustrate and list all parts. Hawkins Ag parts in this manual are specially designed for this machine and should be replaced with Hawkins Ag parts only. -
Page 6: Warranty Information
Introduction Thank you for your purchase of a Hawkins Ag HWT Toolbar. Putting your trust in our equipment is something we don’t take lightly and are humbled that you chose Hawkins Ag. Having designed all of our equipment with farmers like you in mind, we hope you enjoy years of productive use from it. -
Page 7: Safety
If you have questions not answered in this manual, require additional copies, or the manual is damaged, please contact Hawkins Ag, 2120 4th Ave., Holdrege, NE 68949, 308.708.8185, or visit our website: www.hawkinsag.com. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20... -
Page 8: Equipment Safety Guidelines
Observe all safety signs and practice the instructions on them. Never exceed the limits of a piece of machinery. If its ability to do a job, or to do so safely, is in question - DON’T TRY IT. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20... -
Page 10: Safety Sign Locations
SAFETY AWARENESS. Rigid HWT Toolbar 461259 461220 461230 461248 461225 461213 FOLDING HWT Toolbar 461225 461259 461213 461220 461230 NOTE: LH/RH Safety Signs and locations are the same 461248 461250 461255 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20... - Page 11 Keep clear of moving and shifting equipment. Equipment movement area; will result in death or serious injury. • Hazards may include, but are not limited to, connection and disconnection of equipment, unexpected equipment shifting, etc. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20...
- Page 12 No Riders - Warning • Never allow riders on equipment; can result in death or serious injury. • Hazards may include, but are not limited to, falling from equipment, falling into equipment, injury while on equipment, etc. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20...
- Page 13 Use safe practices. Fluid injection can occur; will result in death or serious injury. • Hazards may include, but are not limited to, injury beyond the entry point, over pressurized components, damaged components, components with excessive wear, swollen components, ect. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20...
- Page 14 Do not operate without a complete understanding of the owner’s manual. Do not operate with unsafe practices; may result in death or injury. • Hazards may include, but are not limited to, compromising the safety of yourself and/or others, lack of awareness, damage to equipment, etc. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20...
-
Page 15: Safety Sign Care
Replace safety signs that are missing or have become illegible. • Replaced parts that displayed a safety sign should also display the current sign. • Safety signs are available from Hawkins Ag. How to Install Safety Signs • Be sure that the installation area is clean and dry. -
Page 17: Operation
Operation REmember Your best assurance against accidents is a careful and responsible operator. If there is any portion of this manual or function you do not understand, contact Hawkins Ag. Before Operation • Carefully study and understand this manual. •... - Page 18 If equipment has been altered in any way from the original design, the manufacturer does not accept any liability for injury or warranty. • A first aid kit should be kept readily accessible while performing maintenance on this equipment. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20...
-
Page 19: Before First Use 13
Before First Use Delivered Assembled Hawkins Ag HWT Toolbars leave the factory fully assembled. Hydraulics are installed and tested, wing locking pins are installed in the locked position, hitch pins are installed, leveling bolts are set at level, the light kit is installed and the SMV sign is set down for transportation NOTE: The above is typical;... -
Page 20: Set-Up
Operation Set-up 3-Point Attachment Hawkins Ag HWT Toolbar 3-Point hitches are configured for combination CAT 3/3N/4N or CAT 4N only. When connecting, remove unused pins and ensure connection is secure and tractor is correctly ballasted before lifting equipment. Use caution when working between and/or around moving and shifting equipment Hydraulic Connection Hydraulic lines connect using agricultural quick couplings. - Page 21 Also, ensure that the toolbar is secured and supported adequately to prevent it from tipping over caused by mounting implements and/or equipment that may shift the load. Keep the area clean and always use safe practices. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20...
-
Page 22: Folding Function
Continue until the cylinder is at the end of its stroke and disengage the SCV. Wing stop style and position vary depending on specific toolbar configuration. Refer to the images below for wing and wing stop contact points. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20... - Page 23 • DON’T fold the toolbar with locking pins in the locked position. • DON’T over-pressurize the hydraulic system; HWT Toolbar hydraulics are designed for 3,000 PSI MAX working pressure. • DON’T exceed the limits of a piece of machinery.
-
Page 24: Maintenance
Operation Maintenance • Proper maintenance will ensure longevity and optimum performance of your Hawkins Ag equipment. • Visual inspection is recommended before each use. Check for loose bolts, worn parts, cracked welds and other damage. Replace and repair as needed. -
Page 25: Bolt Torque Chart
(27) (45) (63) 7/16 (41) (72) (100) (61) (110) (155) 9/16 (95) (155) (220) (128) (215) (305) (225) (390) (540) (230) (570) (880) (345) (850) (1320) Bolt Head Identification Grade 2 Grade 5 Grade 8 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20... -
Page 26: Hydraulic Fitting Identification
-4 ORB -4 JIC -4 ORFS -6 NPTF -6 ORB -6 JIC -6 ORFS -8 NPTF -8 ORB -8 JIC -8 ORFS -10 ORB -10 JIC -10 ORFS -12 NPTF -12 ORB -12 JIC -12 ORFS 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20... - Page 27 Checking Hydraulic Fittings • Before connecting hydraulic fittings, check that fittings are clean and undamaged. Replacement fittings and hoses are available from Hawkins AG. • Ensure O-ring(s) are installed properly as shown in the image. (ORB fitting above, ORFS fitting below) •...
-
Page 29: Parts Guide
OUTER BRACKET RH ASSEMBLY FOLDING 302858 (RED, ORANGE, AMBER) OUTER BRACKET RH ASSEMBLY 302862 (RED, ORANGE, AMBER) POSITION MAY VARY NOT SHOWN 302840 COMPLETE RIGID BAR LIGHT KIT NOT SHOWN 302860 COMPLETE FOLDING BAR LIGHT KIT 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20... -
Page 30: Hitch Pins
LOWER HITCH PIN 3N, 3 315162 LOCKING PIN SMALL 315156 RETAINING RING 1 1/4 315158 RETAINING RING 1 7/16 NOT SHOWN 315150 HITCH PIN PACK 3N, 3-4N NOT SHOWN 315165 HITCH PIN PACK 4N ONLY 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20... -
Page 31: Hinge Assembly
HiNGE Assembly *Only on Narrow HWT Toolbars Item Number Part # Description Quantity 306066 HWT HINGE PIN STANDARD (9" BETWEEN TUBES) 411193 1/2-13 X 4 GR5 BOLT 410008 1/2-13 CENTER LOCK NUT 306082 WING LOCKING PIN STANDARD (9" BETWEEN TUBES) 306260 WING LOCKING PIN NARROW (4.5"... -
Page 32: Hydraulic System
RESTRICTION FITTING -8 MALE ORB X -8 FEMALE ORB ELBOW 457261 -8 MALE ORB X -8 FEMALE ORB ELBOW 457274 -10 MALE ORB X -8 FEMALE ORB STRAIGHT 457240 1/2" MALE AG TIP QUICK COUPLER NOTE: FOR HOSE INFORMATION, SEE PAGE 26 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20... - Page 33 5X30 TIE ROD CYLINDER (BASE CLEVIS PIN INCLUDED) 306120 CYLINDER PIN ASSEMBLY (ROD END) 306117 ROD CLEVIS PIN 306118 CLEVIS PIN GUIDE 321672 1 1/4 X 10 GA WASHER 416005 1/4 X 2 COTTER PIN 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20...
-
Page 34: Hose Assembly
176 INCH 204 INCH 16 ROW 38/40 ON-ROW 176 INCH 204 INCH 16 ROW 38/40 INTER-ROW 204 INCH 232 INCH 18 ROW 38/40 ON-ROW 204 INCH 232 INCH 18 ROW 38/40 INTER-ROW 232 INCH 260 INCH 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20... -
Page 35: Bar Stand Assembly
Bar Stand Assembly Item Number Part # Description Quantity 315203 BAR STAND LEG 315201 BAR STAND MOUNT 416230 SNAP LOCK PIN 415004 3/4-10 U-BOLT 7W X 9H 413072 3/4 FLAT WASHER SAE 412062 3/4-10 NUT GR5 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20... - Page 36 308.708.8185 | HawkinsAg.com 2120 4th AVE, Holdrege, NE 68949 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/20...
