PIKA µWARP Hardware Manual
1. Overview
1.1. Interfaces
2. Regulatory Information
2.1. Compliance
3. Appliance Description
3.1. Power
3.2. Ethernet Ports
3.3. USB
3.4. LEDs
4. Technical Specifications
4.1. Physical Properties
4.2. Power Requirements
4.3. Environmental Requirements
5. Glossary
Version
Current Version (v. 2)
v. 1
1. Overview
The PIKA µWARP is a small stand-alone networking appliance used for multiple end user applications such as a Voip Firewall, Virtual Private
Network, Session Border Controller, etc.
1.1. Interfaces
The PIKA µWARP provides the following interfaces:
Two 10/100BaseT network ports
One USB 1.1 host with two type A USB jacks (one is used for connecting power to)
Reset button
Status LEDs
2. Regulatory Information
2.1. Compliance
The appliance is certified compliant for use in the United States, Canada, and European Union countries. The following tables list approval
information for EMC/EMI, Safety standards. Testing for all regulatory disciplines was performed at Nemko Canada product certification and
compliance test facility. The tables list each country or region, its approval standard, registered approval numbers (if any), and a short description
of the approval standard.
The term self-declared indicates that the board was tested by a third-party test facility, but does not require an official approval
number by a country or region's approval standard authority.
