Knaack Power Pass Installation Instructions

To prevent electric shock, explosion, re and/or serious personal
injury when using storage chest with:
Extension Cord -
• Follow all Extension Cord manufacturer's Warnings and
Instructions.
• After removing knock-out, insert Power Pass™ rubber grommet.
Do NOT insert extension cord through hole without grom
met in place (see re 3).
• Only use a three-wire extension cord with all three prongs
intact. Never remove the round grounding prong.
• Extension cord must be connected to a 120 Volt GFCI protected
outlet with proper ground. If GFCI outlet is not available,
use an extension cord with GFCI protection built in.
• Check the insulation and plugs of extension cord before using.
Do NOT use cord if it is worn or damaged.
• Do NOT overload extension cord.
• Remove extension cord from the Power Pass™ hole before
moving or transporting storage chest.
• Only use an extension cord that is rated for outdoor use.
Figure 1, Side View
TOOLS REQUIRED- Hammer and
1. Locate the "knockout".
2. With a screwdriver and hammer, carefully punch out the "knockout" from the inside of the box so that metal ring will fall outside
box re 1).
3. Place the rubber Power Pass™ grommet from the outside of the box in the hole and be sure that it is properly seated. BE SURE
NO SHARP METAL EDGES ARE EXPOSED
4. When passing cords into the box, be sure to always enter box from the rear. After head of cord is in place, slightly pull back
2-3" to ensure weather resistant "star bursts" are facing toward the outside of box
box so that mating plug points are exposed to the environment
5. BE SURE TO FOLLOW ALL ELECTRICAL SAFETY PRECAUTIONS.
If you have any questions, please call our customer service department at 1-800-456-7865.
U.S.-1182982, 1517767, 1897535; Canada-281398; U.K.-1390299; Australia-754070;
"RapidPassThru"-1.eps
TO INSTALL POWER PASS™ RUBBER GROMMET
Figure 2, Inside View
blade screwdriver.
re 2).
Products are protected by one or more of the following patents or trademarks:
N.Z.-296048; other patents pending.
420 E. Terra Cotta Ave, Crystal Lake, IL 60014
INSTALLATION INSTRUCTIONS
Power Pass™ Grommet

WARNING

• Do NOT connect extension cord to outlet that also supplies
critical safety equipment with power.
Cordless Power Tool Battery Chargers -
• See Charger's Owner's Manual for proper use and care of charger
and batteries. Follow all Warnings and Instructions provided
with your battery charger.
• Place chargers and electrical connections in tray.
• Chargers are Dry location use only. Do NOT expose to liquid,
vapor, or rain. Should your charger become wet, Do NOT
attempt to use. Unplug extension cord from supply before
handling wet charger or cords.
• Only use chargers and batteries that are intact and operating
properly.
• Do NOT touch metal prongs when plugging charger into extension
cord.
• Keep
cords or connections.
• Do NOT place or attempt to charge lead acid, car type batteries
in storage chest.
re 3). Never push the cord from inside the
KNAACK LLC
© 2013 Knaack LLC
materials like paper or rags away from charger,
Figure 3, Exterior View
Part No. 14-0021 REV. C ECN 5305 04/13
