Smartphone VR Headset
Art.no 38-8043
Model VA2
Please read the entire instruction manual before using the product and
then save it for future reference. We reserve the right for any errors in text
or images and any necessary changes made to technical data. In the event
of technical problems or other queries, please contact our Customer Services.
Safety
Users should be seated.
Users should remove
Users should take a break
the product immediately if
after 10 minutes of use.
they feel nauseous or faint.
Child users should be accompanied by an adult.
The product must not be used by sufferers of epilepsy.
Responsible disposal
Follow local ordinances when disposing of this product. If you are unsure
about how to dispose of this product contact your municipality.
Specifications
For smartphones with 4.7–5.5" screens
Height
11.7 cm
Depth
12.7 cm
Width
19.4 cm
Weight
315 g
GREAT BRITAIN - CUSTOMER SERVICE contact number: 020 8247 9300 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.co.uk postal: 10 – 13 Market Place, Kingston upon Thames, Surrey, KT1 1JZ
English
Product description
2
3
4
5
1
6
7
8
10
9
11
1. Front cover
9. Right lens
2. Trigger/Action button
10. Touchscreen stylus pad
3. Padding
11. Left lens
4. Headband attachment point
12. Hole for smartphone camera.
5. Headband attachment point
Note: Compatible with most
6. Smartphone cradle
smartphones but there may be
7. Right pupil and
exceptions.
focus adjuster
13. Side hole for head phone/
8. Left pupil and
charger cable
focus adjuster
Operating instructions
Download the desired app to your smartphone.
1. Open the front cover (1) by releasing the catch at the top and letting
the cover fall forwards.
2. Adjust the phone cradles (6) to suit the size of the smartphone.
Move the cradles up/down, left/right as
shown by the arrows.
12
The phone is positioned correctly when
the bottom corners of the phone both
sit fully in the cradles and the middle of
the display screen is centred between
the two lenses of the VR headset.
3. Run the desired app and place the smartphone into the now form-fitting
VR headset. Thereafter, close the front cover securely.
13
4. Put the VR headset
on and adjust
the head band so that
it fits comfortably.
5. Adjust the focus by moving the two
focus adjusters (7 and 8) forwards/
backwards.
6. Adjust the interpupillary distance
by moving the adjusters (7 and 8)
left/right.
7. Trigger/Action button. This button
controls a soft-tipped touchscreen
stylus pad (10) for selecting functions
and triggering actions in a number of
VR games.
Care and maintenance
Clean the product by wiping it with a soft, dry cloth.
