Summary of Contents for Snap Fresh BBT-JOL01
- Page 1 User Manual CORDLESS RECIPROCATING SAW BBT-JOL01 geprufte Sicherheit Read all safety rules and instructions carefully before operating this tool.
-
Page 2: Table Of Contents
CONTENTS ....................................Contents ....................................... Symbols ..............................Safety instructions Machine information ................................................................Assembly 8-13 ..................................Operation 13-14 ..................................Maintenance ................................... Environment ....................................Warranty... -
Page 3: Symbols
SYMBOLS The following symbols are used in the user manual or on the product: Class II machine - Double insulation Read the user manual. You don’t need any earthed plug. Denotes risk of personal injury, loss of life or damage to the tool in case of Time-lag miniature fuse-link. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Read the enclosed safety warnings, the additional safety warnings and the instructions. Failure to follow the safety warnings and the instructions may result in electric shock, fire and/or serious injury. Save the safety warnings and the instructions for future reference. GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. - Page 5 Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
- Page 6 SAFETY WARNINGS FOR RECIPROCATING SAWS • Hold power tool by insulated gripping surfaces,when performing an operation where the cuting accessory may contact hidden wiring. Cutting accessory contacting a “live” wire may make exposed metal parts of the power tool “live” and could give the operator an electric shock. •...
-
Page 7: Machine Information
It is suitable for straight and curved cuts. It is also possible to cut ush to the workpiece surface. A suitable saw blade must always be used. TECHNICAL SPECIFICATIONS Model Number BBT-DC20A Model No. BBT-JOL01 Battery Type Lithium-Ion Rated voltage Voltage No load speed 0-3000/min. -
Page 8: Assembly
Only use the following batteries of the SnapFresh power 20V battery platform. Using any other batteries could cause serious injury or damage the tool. BBT-DC20A 20V, 2Ah Lithium-Ion BBT-DC40A 20V, 4Ah Lithium-Ion The following charger of the can be used to charge these batteries. BBT-YFT20V Quick charger The batteries of the SnapFresh power 20V battery platform are interchangeable with all the SnapFresh... - Page 9 • •...
- Page 11 Before any work on the power tool, remove the battery. The battery must be charged before first use. DESCRIPTION The numbers in the text refer to the diagrams on page 8-10. 1. Lock-off button 2. On/Off button 3. Handle 4. Battery 5.
- Page 12 Charging the battery with the charger (Fig. G) • Take the battery (4) from the machine. • Turn the battery (4) to upside down position and slide it onto the charger (15) as shown in Fig. G. • Push the battery until it is fully pushed into the slot. •...
-
Page 13: Operation
Mounting the saw blade Make sure the blade holder is free of material debris (such as splinters of wood or metal). • Turn the clamping lever (9) as far to the left as possible and hold it in this position. •... -
Page 14: Maintenance
Flush cutting (Fig. E) Elastic bi-metal saw blades allow you to saw protruding objects (e,g, water pipes, iron bars, etc,) nearby the wall. • Apply the saw blade directly to the wall and bend slightly so that the footplate rests against the wall. -
Page 15: Warranty
WARRANTY Babytec Technology Co., Ltd® warrants this product against defects in materials and/or workmanship under normal use for a period of ONE (1) YEAR from the date of purchase by the original purchaser (’Warranty Period’). The following circumstances are excluded from this guarantee: •...
