Summary of Contents for Impact Acoustics 40430
- Page 1 Remote Control Repeater Model: 40430 Operation Manual Ver.1.0...
-
Page 2: Operation Manual
Operation Manual Remote Control Repeater Model: 40430 Thank you for purchasing Remote Control Repeater. We recommend that you read this manual thoroughly and retain for future reference. Function: The Remote Control Repeater is a system that repeats the signal of your audio/video device remote control. -
Page 3: Table Of Contents
Table of Contents Function...…………………………………………………………………………..ii Package Contents………………………………………………………………...ii Features…………………………………………………………………………….1 Connecting the Remote Control Repeater...….…………………………………1 Specifications……………………………………………………………………...4 Replaceable Parts...4 Warranty/Important Safety Information…………………………………………..5... -
Page 4: Features
Features: • CFL friendly This unit can be installed in an area with compact fluorescent lighting, and will work in most lighting environments • IR LED Blue IR LED confirms the signal is being transmitted • Wide Band IR Wide Band IR receives infrared signal from many types of remotes •... - Page 5 Diagram of connections: Connecting the IR Receiver Connecting the Dual Emitters Connecting the AC Adapter via wall outlet Connecting the AC Adapter via stereo receiver...
- Page 6 Examples of mounting the IR Emitter Note: Make sure that the mounting surface is clean and dry before mounting the IR Emitter Standard Installation: Attach the IR Emitter directly on your device’s IR sensor window Attach the IR Emitter above or below of the IR window Attach the IR Emitter to the inside of a cabinet door, with...
-
Page 7: Specifications
Specifications Receive Frequency Range Transmit Frequencies Range Power Dimensions (IR Receiver) (IR Connecting Block) Cord Length (IR Receiver) (IR Emitters) Connector Type Weight (IR Receiver) (IR Connecting Block) Replaceable Parts In the event of a lost or damage part, the following replaceable accessories are available. -
Page 8: Warranty/Important Safety Information
Impact Acoustics™ One Year Warranty At Impact Acoustics, we want you to be totally confident in your purchase. That is why we offer a one year warranty on this device. If you experience problems due to workmanship or material defect for the duration of this warranty, we will repair or replace this device. To request a Return Merchandise Authorization (RMA) number, contact customer service at 877-AV-EXPERT or www.impactacoustics.com.
