  • Page 1 DP-D Gen2 Series User’s Manual Version 25.02.2021 DP-D Gen2 Series High Power Laboratory Power Supplies User’s Manual • • by DSC-Electronics Germany Georgstraße 36 53111 Bonn DSC-Electronics Germany • Georgstraße 36 • 53111 Bonn DSC-Electronics Germany • Georgstraße 36 • 53111 Bonn...
  • Page 2 DP-D Gen2 Series User’s Manual Version 25.02.2021 1. Connection Our devices are pre-configured to the power grid chosen with order (if not specified otherwise, our devices are manufactured for the EU power grid 230V 50Hz / 400V 50Hz). Subsequent adjustment after delivery is not possible.
  • Page 3 DP-D Gen2 Series User’s Manual Version 25.02.2021 2. General Please read through and understand this Operation Manual before operating the product. After reading always keep the manual nearby so that you may refer to it as needed. When moving the product to another location, be sure to bring the manual as well.

  • Page 4: Product Description

    Note: Can be ignored for devices with optional capacitive reverse current protection. In the basic version, power supplies of the DP-D Gen2 series are not protected against reverse currents, which can lead to a reverse current from the capacitive load after switching off the output voltage of the power supply. Never connect pre-charged capacities to the power supply unit unless you have connected a serial protection diode between the load and the power supply.

  • Page 5: Front Panel Description

    DP-D Gen2 Series User’s Manual Version 25.02.2021 3.3 Inductive load Note: Can be ignored for devices with optional inductive reverse current protection. If the power supply is used with large inductive loads, voltage spikes with an amplitude of up to 5 times the output voltage can occur, this may damage the power supply or lead to unstable operation.
  • Page 6 DP-D Gen2 Series User’s Manual Version 25.02.2021 Name Description RS-232 Interface Standard interface. RS-485 Interface Standard interface. RS-485-Interface Standard interface. Analog control switch Enable / Disable external analog control (Optional). Output terminals Positive and negative output terminals. AC input terminals AC mains connection.
  • Page 7 DP-D Gen2 Series User’s Manual Version 25.02.2021 Name Description RS-232 Interface Standard interface. RS-485 Interface Standard interface. RS-485-Interface Standard interface. Analog control switch Enable / Disable external analog control (Optional). Output terminals Positive and negative output terminals. AC input terminals AC mains connection.
  • Page 8 DP-D Gen2 Series User’s Manual Version 25.02.2021 5.3 Constant current operation NOTE: Pressing the voltage or current knob shortly switches between coarse and fine tuning. 1. Turn on the power and check that the output is off. 2. Press the SET button and set the desired voltage and current limit according to point 5.2.
  • Page 9 DP-D Gen2 Series User’s Manual Version 25.02.2021 6.6 Panel lock The panel lock function is designed to avoid inputs by mistake. Short press [Lock] key to lock operations of front panel keys and knobs. The “Lock” icon appears the lower left corner of the LCD screen when the front panel is locked.
  • Page 10 DP-D Gen2 Series User’s Manual Version 25.02.2021 6.7.2 Serial communication Press the [Tab] button to select the “UART” menu. In this menu, parameters of baud rate, stop bit, parity bit and communication ID can be adjusted. Press < > keys to move the cursor to select a parameter, and then use the rotary knob to set the value.
  • Page 11 DP-D Gen2 Series User’s Manual Version 25.02.2021 6.7.4 Date and time Press the [Tab] button to select the “DATE & TIME” menu. Press the < > keys to move cursor to select a parameter, and then use rotary knob to set the value.
  • Page 12 DP-D Gen2 Series User’s Manual Version 25.02.2021 6.7.6 Cycle mode settings Press the [Tab] button to select the “CYCLE MODE” menu. There are 4 cycle configuration options: 10 group * 100 item (100 steps in each group, in total 10 groups)
  • Page 13 DP-D Gen2 Series User’s Manual Version 25.02.2021 Press the < > keys or turn the rotary knob to move the cursor to the row entitled as “Cycle:, OVP:, OCP:”, the cursor position is highlighted in blue as above. Function keys F1-F4 now correspond to Cycle No. [Cycle], OVP value [OVP], OCP value [OCP] and [BackSpace] key respectively.
  • Page 14 DP-D Gen2 Series User’s Manual Version 25.02.2021 6.7.7 V Slope mode In voltage slope mode, the output voltage rise time or fall time can be adjusted. After setting up rise time or fall time, the output voltage rises or falls gradually within the preset time. Otherwise, the output voltage rises or falls at the maximum speed.
  • Page 15 DP-D Gen2 Series User’s Manual Version 25.02.2021 Press the < > keys or turn the rotary knob to move the cursor to the first row of the table, the cursor position is highlighted in blue as above. Function keys F1-F4 now correspond to Step No. [Step], Voltage value [V(V)], Current value [I(A)], time value [Hr Min Sec] and [BackSpace] key respectively.

  • Page 16: Optional Features

    (true = on/false = off) if the „Output On/Off“ switch of the power supply is always in the ON position. 8. Digital control 8.1 RS-232 Interface Following the pin description of the RS-232 interface of the DP-D Gen2 Series. Pin out definition Function Blank...
  • Page 17 DP-D Gen2 Series User’s Manual Version 25.02.2021 8.2 RS-485 Interface Following the pin description of the RS-485 interface of the DP-D Gen2 Series. Pin out definition Function A (D+) B (D-) Space for your notes: DSC-Electronics Germany • Georgstraße 36 • 53111 Bonn...
  • Page 18 DP-D Gen2 Series User’s Manual Version 25.02.2021 9. Communication Protocol for DSC-Electronics DP-D Gen2 Series power supplies Interface: RS-232 / RS-485 (Profibus DB) / LAN (Only with option[Y]) Command format: Asynchronous, 1 start bit, 8 data bits, 1 stop bit UART baud rate: 1200;...
  • Page 19 DP-D Gen2 Series User’s Manual Version 25.02.2021 9.1 Command Examples 9.1.1 Output ON/OFF Control command: Function Code Register Address Data (On/Off) CRC Check Code 0085 FF00 9DD3 0085 0000 DC23 Feedback: Equal to command. 9.1.2 Read Output Status Control command:...
  • Page 20 DP-D Gen2 Series User’s Manual Version 25.02.2021 Control command: Function Code Address of First Register Numbers of Registers CRC Check Code 006E 0003 DID6 Feedback: Function Code Bytes CRC Check Code 0000 007F 02E8 F9F1 0x0000 = 0kW 0x007F = 127W...
  • Page 21 DP-D Gen2 Series User’s Manual Version 25.02.2021 2) Set Voltage Value of Sequence Number 1 to X For example, set voltage values of sequence number 1, 2 and 3 at 2.4V, 3.4V and 5.4V respectively. Function Code Address of Numbers of...
  • Page 22 DP-D Gen2 Series User’s Manual Version 25.02.2021 9.2 Command Frame 9.2.1 Function Code Below function codes are supported. Function Function Description Bit Operation / Numbers of Operation Code Code HEX Byte Operation 0x01 Read cycle status Bit Operation Single or multiple...
  • Page 23 DP-D Gen2 Series User’s Manual Version 25.02.2021 9.2.2 Register Definition Input Register Address Address Function Code Type Description Target (Decimal) (Hex) 04 (Read) Read Output voltage (feedback value) 0x0064 Byte √ Read Output current (feedback value) 0x0065 Byte √ Read...
  • Page 24 DP-D Gen2 Series User’s Manual Version 25.02.2021 Discrete Input Status Function Code Address Address Type Description Target (Decimal) (Hex) 02 (Read) Read Constant Current mode (CC) 0x0074 √ Read Constant Voltage mode (CV) 0x0075 √ Read Reserved 0x0076 Read Reserved...
  • Page 25 DP-D Gen2 Series User’s Manual Version 25.02.2021 Holding Register Function Code Address Address Type Description Target (Decimal) (Hex) (Read) (Write (Write single) multiple) 0x0094 Byte √ √ √ Voltage setup value 0x0095 Byte √ √ √ Current setup value 0x0096 Byte √...
  • Page 26 DP-D Gen2 Series User’s Manual Version 25.02.2021 Holding Register Function Code Address Address Type Description Target (Decimal) (Hex) (Read) (Write (Write single) multiple) Start step in I-Slope mode 0x00b4 Byte √ √ √ End step in I-Slope mode 0x00b5 Byte √...
  • Page 27 DP-D Gen2 Series User’s Manual Version 25.02.2021 Holding Register Function Code Address Address Type Description Target (Decimal) (Hex) (Read) (Write (Write single) multiple) Running time of sequence X in 1200+X Byte √ √ √ Cycle Mode Running time of sequence 100 in...

  • Page 28: Device Check

    DP-D Gen2 Series User’s Manual Version 25.02.2021 Note: Registers marked yellow are only available on devices with option [Y]. Remark 1: The output power and load resistance are calculated from the voltage and current readback values. To get the present output power, you need to read the data of three addresses of kilowatts (KW), watts (W), and milliwatts (mW) at one time.
