Ins-30076 TOUCHLOCK compact K series

Advertisement

loading

Related Manuals for Paxton Access TOUCHLOCK K Series

Summary of Contents for Paxton Access TOUCHLOCK K Series

  • Page 1 Ins-30076 TOUCHLOCK compact K series ...

  • Page 2: Technical Support

    Saturday from 09:00 - 13:00 (GMT) Documentation on all Paxton Access products can be found on our web site - http://www.paxton.co.uk/ Quickstart guide This supplement is a brief guide to installing a TOUCHLOCK K series compact system. Further information is available for download at: http://paxton.info/140 or call the communications team on: +44 (0)1273 811011.
  • Page 3 Wiring 12v DC NOTE: Illustrations in this instruction show the Lock 12V standard keypad. Lock 0V The Stainless Steel version installs and Exit input operates in exactly the  same manner. Exit 0V Bell 12V Bell 0V K75 Screw connector option NOTE: The unit should be mounted in conjunction with an electrical backbox to achieve the required clearance for...

  • Page 4: Factory Reset

    Factory reset 1. Power down the system. 2. Power the system up whilst pressing and holding 3. 3. All 3 LED’s will flash and the unit will beep 3 times a second. 4. Go to TOUCHLOCK programming guide. - Initialising a new system. Initialising a new system A 6 digit Programming Code must be set by the user first.
  • Page 5 START - Enter the 6 digit Programming Code and hold down a function key ----- for 3 seconds. - The unit beeps and the LED flashes faster. Continue the key sequence to set the option - The keypad returns to operating mode. Enter user code Re-enter Set a...
  • Page 6 Fitting Keypad bezels Additional bezels are available in black, white, grey, blue and silver. Registered installers can order these free of charge by logging onto the secure installer extranet: https://extranet.paxton-access.co.uk/index.asp. If you are not a registered installer please call us on: +44 (0)1273 811011 for more information.

  • Page 7: Frequently Asked Questions

    Frequently asked questions Here is the list of topics about this product that receive the most technical support enquiries. We list them here to help you speed up the installation and trouble shooting process. 1 - Can I use a fail open release (e.g. Maglock)? QThe lock wires from a compact keypad provide 12V DC to the electric lock.

  • Page 8: Specifications

    Pozi pan self tapping screw - small Cable clips This product is not suitable for retail sale. All warranties are invalid if this product is not installed by a competent person. Ins-30076 TOUCHLOCK compact K series © Paxton Access 2008 04/08/2008...
