Delta Electronics AC MAX Basic Quick Installation Manual page 22

Version
Charging mode
Charging interface
Input/output rating
Input wiring
Standby power
Altitude
Internal residual current detection
Surge protection
Electrical protection
Cold load pick-up
Status indicators
Buttons/Switches
Operating temperature
Storage temperature
Relative humidity
Length of charging cable
Ingress protection
Impact protection
Cooling
Dimension (H x W x D)
Net weight
Compliance/ certificate
* Depends on model configuration.
22
Basic
Mode 3
IEC 62196-2: Type 1 plug, Type 2 plug, Type 2
socket, or Type 2 socket with shutter
220-240 V
AC
380-415 V
AC
Single-phase: L1, N, PE
Three-phase: L1, L2, L3, N, PE/ L1, L2, L3, PE (IT)
< 2,6 W*
2000 m
AC 30 mA, DC 6 mA
Class II
Over current protection, short circuit protection,
over voltage protection, under voltage protection,
ground fault protection, surge protection, over
temperature protection
Randomized delay between 5 and 100 seconds
before the charge resume after power outages.
Blue, green, red, yellow
Key switch
-30ºC to +50ºC (-22ºF to +122ºF)
-40ºC to +80ºC (-40ºF to +176ºF)
< 95%, non-condensing
5 m, straight cable
IP55
IK09
Natural cooling
371 x 218 x 167 mm (14.6 x 8.6 x 6.6 inch), exclu-
ding charging cable, mounting bracket and cable
holder
3.9 kg*
CE, UKCA
AC_MAX_BASIC_QIG_EU_V1.0.0_2021-03
, 1~, 16 A or 32 A max., 50-60 Hz
, 3~, 16 A or 32 A max., 50-60 Hz
