- Page 1 ASENWARE LTD. DDRESSABLE LARM ONTROL ANEL July, 2017 Prepared By : AK...
- Page 2 ASENWARE LTD. CHAPTER 1 GENERAL INFORMATION 1.1 INTRODUCTION Asenware AW-FP100 Series Fire Alarm Control Panel are intelligent panel which are carefully designed to make it suitable for most of applications. It can be configured with other panels or control systems. It’s user friendly functionality makes it suitable to program and configure the devices.
- Page 3 ASENWARE LTD. 1.3 DISPLAY AND FUNCTION KEYS Large display screen makes the panel easily programmable, below Figure 1.1 shows LED indicators and functions keys available 1.3.1 Liquid Crystal Display It displays all programming screens, as well as events, history, device and other information. At normal condition it displays Fire, Fault , Supervisory and general information.
- Page 4 ASENWARE LTD. 1.3.3 LED Indicators Table 1.1 LED Indicators LED INDICATOR COLOR FUNCTION Power Greeen Illuminate when power supply is on Fire Alarm Illuminates when at least one fire alarm event exists General Fault Yellow Illuminates when at least one fault occurs...
- Page 5 ASENWARE LTD. 1.4.3 Input Method From the display, it is very convenient for the programmer to input and register the devices. 1.4.4 Power Supply The power supply is designed to supply power to all devices in the system. The system adopts...
- Page 6 ASENWARE LTD. 1.4.8 Printed Circuit Board The control panel electronics are contained on one printed circuit board that incorporates with loop cards and the central processing unit (CPU). The built-in power supply includes an integral battery charger. A display unit is connected over the PCB.
- Page 7 ASENWARE LTD. TECHNICAL PARAMETERS 1.5.1 Power Rating Mains power supply: AC 220V±20%/50Hz or DC24V; Backup power supply: DC24V maintenance-free battery BAT12V/5AH 1.5.2 Environmental Condition Ambient temperature: -10℃～+55℃ Ambient humidity: ≤95% (40℃±2℃, no condensation) 1.5.3 Terminals Refer to product instructions for detailed technical parameters of the detector, module, sounder...
