CD35IR-SH24 / 14IR LEDs Ceiling mount 360° Color Day & Night CCD Camera
Pick-up device:
Picture elements HxV:
Horizontal resolution:
Vertical frequency :
Scanning system:
Minimun Illumination:
Synchronization:
S/N Ratio:
White Balance:
Electronic shutter:
Lens:
Gamma:
Video Output:
Gain Control:
Power supply :
Power Consumption :
Color :
Weight:
* Bracket sold separately
SONY Color CCD Image Sensor
NTSC:512 x 492 - PAL:512 x 582
420 TVL
EIA//NTSC: 59.94 HZ - CCIR/PAL: 50 HZ
2:1 interlace
0 Lux Day & Night w/ IR on
Internal
>48dB
Auto White Balance
UP TO 1/100.000sec
3.6mm Lens
0.45
1Vp-p, 75 Ohms
AUTO
12V DC (+/-10%)
350mA (+/-10%)
Black
1.5lbs - 680g
Advertisement
Related Manuals for Sony CD35IR-SH24
Summary of Contents for Sony CD35IR-SH24
- Page 1 CD35IR-SH24 / 14IR LEDs Ceiling mount 360° Color Day & Night CCD Camera Pick-up device: Picture elements HxV: Horizontal resolution: Vertical frequency : Scanning system: Minimun Illumination: Synchronization: S/N Ratio: White Balance: Electronic shutter: Lens: Gamma: Video Output: Gain Control:...
- Page 2 Storage Temperature : Operation Temperature : -30°C ~ 60°C -10°C ~ 50°C * Pictures and specifications are subject to change without prior notice...
