CNET Pro200 Specifications

TOTAL NETWORK SOLUTIONS
The new PRO200 Adapter is an exciting new 100/10Mbps dual speed Fast Ethernet Adapter. This model is equipped
with an Auto-Negotiation function that automatically supports data transmission bandwidths ranging from 10Mbps -
200Mbps. This function smoothly and automatically switches drivers between 100Mbps and 10Mbps, Full or Half-
Duplex, LAN connections.

Key Features

=
Single-chip PCI Bus 100BASE-TX Fast
Ethernet.
=
Fully compiles with IEEE 802.3u and IEEE
802.3 standards .
=
Full-Duplex available in both modes for up to
200Mbps throughput.
=
Optimal line-speed set automatically via Auto-
Negotiation function.
=
Shielded RJ-45 connector provides unified
100BASE-TX and 10BASE-T network media
interface.
=
Complies with PCI specification 2.1, 2.2, ACPI
1.0, and PCI Bus Power Management 1.1.
=
3.3V main power supply for LAN Controller.
Product Name
Drivers
Standards
BUS Type
Network Interface
Network Modes Supported
LED's
Environment
Dimensions
Specifications are subject to change without notice
PRO200 10/100 M
Fast Ethernet PCI-Bus Adapter
Netware 3.x, 4.x, 5.x
Windows 95/98 and OSR2
Windows NT, Windows 2000
Windows ME
Windows for Workgroups
LAN Manager
SCO UNIX
IEEE 802.3u 100BASE-TX
IEEE 802.. 10-BASE-T
PCI Bus specification revision 2.1, 2.2.
One (1) shielded RJ-45 phone-type jack
100BASE-TX (Category 5 TP cable required)
10BASE-T (Category 3, 4, and 5 TP supported)
Full-Duplex available in both modes
ACT/LINK (Green)
Operating Temp.: 0° ~ 55° C (32° ~ 131° F)
Storage Temp.: -20° ~ +70° C (-4° ~ 158° F)
Humidity: 10% ~ 90% non-condensing
120 x 38 mm (4.78 x 1.50 inches)
F E
BPS AST THERNET
www.cnetusa.com
=
Device drivers Certified by Novell, Microsoft
PC99, and Linux RedHat 6.0.
=
EMI and EMC compliance with FCC Class B
and CE mark emission standards.
NCSA
PC/TCP
Sun PC-NFS
DEC Pathworks
Banyan Vines
Client 32
DOS ODI
Linux
Trademarks & Trade Names belong to their owners
PCI-B A
US DAPTER
