Installation Guide of Controllerless USB V.92 Modem
Support O/S
1. Windows 9x
2. Windows ME
Outlet Description
LED DESCRIPTION
OH Off Hook Indicator
Lights when the modem picks up or answer the telephone line.
TR Transmit / Receive Indicator
Flashes when transmit or receive data.
3. Windows 2000
4. Windows XP
1
Advertisement
Related Manuals for CNET CNUM56-RC
Summary of Contents for CNET CNUM56-RC
- Page 1 1. Windows 9x 2. Windows ME Outlet Description LED DESCRIPTION OH Off Hook Indicator Lights when the modem picks up or answer the telephone line. TR Transmit / Receive Indicator Flashes when transmit or receive data. 3. Windows 2000 4. Windows XP...
-
Page 2: Hardware Connection
Hardware Connection Connection Method 1. Line: Connect to your telephone line by RJ11 cable 2. Phone: Connect to your telephone set by RJ11 cable 3. USB Port: Connect to your PC by USB cable... -
Page 3: Software Installation
Windows will report that it has found a new hardware and will open the “Add New Hardware Wizard” reporting that is searches for the new drivers for a “V.92 Modem with USB Interface” device. Click Next. To search for the best drivers for your device, click Next. - Page 4 Windows will show the message ”Windows driver file search for the device “Controllerless USB V.92 Modem” and show the location of driver. Click Next Click Finish to complete the installation procedures.
- Page 5 Installation Procedures for Windows ME Connect the USB modem to PC with USB cable. Windows will find new hardware and ask for driver. Select “Automatic search for a better driver” and then click Next to begin installation. Select Controllerless USB V.92 Modem whose location is E:\DRIVERS\WINME (E is your CD-ROM drive.) and then click OK.
- Page 6 Installation Procedures for Windows 2000 Connect the USB modem to PC with USB cable. When Windows detects the modem, the wizard will help you to install the new device. Click Next to begin installation. Select “Search for a suitable driver for my device”. Then click Next.
- Page 7 Click Browse and indicate the path: E:\Drivers\Win2K_XP. (E is your CD-ROM drive.) Then click OK. Wizard will find the correct driver for the new device. Then click Next. Read the Digital Signature and then click Yes. 10. Windows has finished installing the software. Click Finish to complete installation.
- Page 8 Installation Procedures for Windows XP Connect the USB modem to PC with USB cable. When Windows detects the modem, the wizard will help you to install the new device. Insert the driver CD into your CD-ROM drive. Select “Install the software automatically”...
