About BlueSoleil
BlueSoleil is a Windows-based software from IVT that allows your Bluetooth?enabled desktop
or notebook computer to wirelessly connect to other Bluetooth enabled devices. BlueSoleil
allows MS Windows users to wirelessly access a wide variety of Bluetooth enabled digital
devices, such as cameras, mobile phones, headsets, printers, and GPS receivers. You can also
form networks and exchange data with other Bluetooth enabled computers or PDAs.
In order to connect and share services via Bluetooth wireless technology, two devices must support
the same Bluetooth Profile(s) as well as opposite device roles (i.e., one must be the server, and the
other must be the client). Bluetooth enabled devices often support multiple profiles, and if involved
in multiple connections, can perform different device roles simultaneously. BlueSoleil supports the
following Bluetooth functions (Profiles) in the following device roles:
Bluetooth
Functions
(Profiles)
AV
Headphone*
Basic Image
Profile
Dial-Up
Networking
Fax
File Transfer
Headset*
Human
Interface
Device
LAN access
Object Push
Personal Area
Networking
Printer
Serial Port
Synchronization
Notes:
Only one Headset or AV Headphone connection can exist at a time, since there is only one virtual
Bluetooth audio device.
Client
Server
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
ˇ
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for IVT CBD-120
Summary of Contents for IVT CBD-120
- Page 1 About BlueSoleil BlueSoleil is a Windows-based software from IVT that allows your Bluetooth?enabled desktop or notebook computer to wirelessly connect to other Bluetooth enabled devices. BlueSoleil allows MS Windows users to wirelessly access a wide variety of Bluetooth enabled digital devices, such as cameras, mobile phones, headsets, printers, and GPS receivers.
- Page 2 The Headset and AV Headphone Profiles do not work on Windows 98SE or Windows Me. Platforms supported by BlueSoleil include: Windows 98SE/ME Windows 2000/XP Copyright The information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronically or mechanically, for any purpose, without the express written permission of IVT Corporation.
-
Page 3: Getting Started
Getting Started Basic operations for Bluetooth: Start Bluetooth Establish Bluetooth connection BlueSoleil supported Bluetooth functions: AV Headphone Basic Imaging Bluetooth Synchronization Dial-Up Networking File Transfer Headset Human Interface Device LAN Access Object Push Personal Area Network Printer Serial Port For Bluetooth securities, please see: Bluetooth Security... -
Page 4: Start Bluetooth
1. Insert the USB dongle to your computer. 2. Start BlueSoleil. The plug in and pull out of the USB dongle can be detected by BlueSoleil. You can start BlueSoleil first and then plug in a USB dongle. Some Bluetooth CompactFlash cards cannot be detected when they are plugged in. Please configure the devices' parameters first. -
Page 5: Establish Bluetooth Connection
Establish Bluetooth Connection A connection is normally initiated from the client. On the server side, start the service. On the client side, initiate the connection. Start Service on Server If BlueSoleil provides service, please start the service: 1. Change to Service Window. 2. -
Page 6: Bluetooth Security
Bluetooth Security To modify your connection? Security settings, click My Bluetooth | Security. BlueSoleil offers three security levels: Low (Security Mode 1, No security) No security procedure is needed for connections. Medium (Security Mode 2, Service level enforced security) Authentication or Authorization is requested when a specific service is accessed by other Bluetooth enabled devices. -
Page 7: Basic Imaging
Basic Imaging The Basic Imaging Profile (BIP) enables users to receive pictures from a Bluetooth device such as digital camera, mobile phone, or other compatible device. It also enables remote control of shooting, display, and other imaging functions. Typical Usage •... -
Page 8: Dial-Up Networking
Figure 2 Service Configuration Dial-up Networking The Bluetooth Dial-up Networking (DUN) Profile enables users to wirelessly dial-up to Internet through a Bluetooth modem or a mobile phone that supported the DUN Profile. Typical Usage • Dial-up to Internet via a Bluetooth enabled mobile phone. •... - Page 9 Figure 1 Dial-Up Dialog Note: After you successfully connect, a screen will ask if you would like to create a dial-up shortcut on your desktop. This would allow you to conveniently dial up and connect by simply clicking on the shortcut, without having to manually start BlueSoleil.
-
Page 10: File Transfer
File Transfer The File Transfer Profile (FTP) enables users to transfer files and/or folders between Bluetooth enabled laptops, desktops, PDAs, mobile phones, etc. Typical Usage • Connect to a Bluetooth enabled mobile phone and transfer files or folders to/from the phone. •... - Page 11 Figure 1: Service Configuration...
-
Page 12: Human Interface Device
Headset The Headset Profile enables users to use a Bluetooth headset as wireless earplug or microphone. Typical Usage Use Headset as a device for audio input/output. Use Headset as Sound Input/Output Device Steps: 1. Connect to the Bluetooth enabled headset. 2. - Page 13 The Bluetooth LAN Access Profile (LAP) allows users to access a Local Area Network (LAN) via a Bluetooth enabled LAN access point. Typical Usage • Accesses a Local Area Networking via a Bluetooth enabled LAN access point. • Use your computer as a LAN Access Point. Access a LAN via a Bluetooth enabled Access Point (AP) 1.
- Page 14 Figure 2 : Select Properties On the Pop-up Menu (2) Select Incoming Connections Properties | Networking -> Internet Protocol (TCP/IP),...
-
Page 15: Object Push
(3) Select Specify TCP/IP addresses and enter the range of IP addresses assigned to LAP clients (Figure 4). Figure 4 : Enter the IP Addresses Note: In order to use a Windows 98SE/Me system as an access point, you must have already installed a Dial-up Adapter and the Windows Direct Cable Connection component on the system. - Page 16 Push Objects to a Bluetooth Mobile Phone There are two ways to push objects: 1. From BlueSoleil Main Window: Double-click on the mobile phone or PDA icon to browse for service information. The Object Push Service icon should be highlighted at the top of the screen. Right click the Object Push Service icon, and in the pop-up menu click Send My Card.
- Page 17 Figure 2 Outlook Bluetooth Add-in (3) The Bluetooth Neighbors screen will appear. In the device list, select the phone or PDA that Figure 3 Select the Remote Device Receive Objects from a Bluetooth Phone Steps: 1. Configure the parameters for the object push. From the Main Window, click My Service | Properties.
- Page 18 Figure 1: Object Push Service Configuration 2. Start Object Push service. Do not initiate a connection, only start the service so that your computer will be ready to receive objects. 3. Send objects from the phone. For instructions, refer to your phone's user documentation. Notes: •...
-
Page 19: Personal Area Networking
Personal Area Networking The Bluetooth Personal Area Networking (PAN) Profile enables PCs, laptops, PDAs, and other Bluetooth enabled devices to form either of two kinds of PAN networks. In a Group ad-hoc Network (GN), which functions as an isolated network, multiple PAN Users (PANUs) are linked together via a GN controller. - Page 20 Connecting the PAN User (PANU) 1. Connect to the server's Personal Area Network service . 2. Wait for a few seconds for BlueSoleil to obtain and display your computer's IP address. Configuring the NAP/GN Click Bluetooth Service | Properties and click on the Personal Area Network tab. •...
- Page 21 Figure 4: Access LAN Network •Scenario 3 : Access Internet via NAP Select Access Internet and select a physical network adapter, through which the NAP connects to Internet, as the WAN Adapter (Figure 5). It will automatically enables NAT (Network Address Translation, please refer to Windows Help Topic) function and a DHCP server.
- Page 22 Printer The Bluetooth Printer Profile (HCRP) enables your compter to connect to a Bluetooth enabled printer. Typical Usage • Print documents to a Bluetooth enabled Printer. Print Documents to a Bluetooth Printer 1. Connect to the printer's printer service. 2. (a) If your computer does not have the correct printer drivers installed, BlueSoleil will prompt you to do so (Figure 1).
-
Page 23: Serial Port
Serial Port The Bluetooth Serial Port Profile (SPP) provides PCs, laptops, PDAs, GPS receivers, cordless serial adapters, and other Bluetooth enabled devices with a virtual serial port, enabling them to connect with each other wirelessly via Bluetooth instead of a serial cable. BlueSoleil supports four Bluetooth Serial Ports for out-going connections and two Bluetooth Serial Ports for incoming connections. -
Page 24: Bluetooth Synchronization
Bluetooth Synchronization The Bluetooth Synchronization (SYNC) Profile enables users to synchronize PIM objects on their computer with that of other Bluetooth enabled computers as well as Bluetooth enabled mobile phones, PDAs, and other devices. Four kinds of objects are supported: •... - Page 25 BlueSoleil User Guides This chapter describes BlueSoleil User Interface and how to do various configurations and operations. It includes: • BlueSoleil Environment • Bluetooth Connection Management • Configurations • Bluetooth Security For details on how to use Bluetooth profiles in BlueSoleil , please refer to Getting Started with BlueSoleil...
-
Page 26: Bluesoleil Environment
BlueSoleil Environment • Main Window • Service Window • Menus Main Window Main Window displays the local device (red ball) and the remote devices detected in range. Connecting and disconnecting operations are conducted here. Connections are indicated in lines between the local device and connected remote devices. By default BlueSoleil starts with the Main Window open. - Page 27 Icons: Icon Meanings: Remote devices can be in any of three states, which BlueSoleil indicates with different colors. • White- Idle. The normal state of the device. • Yellow- Selected. you have selected the device. • Green- Connected. The device is connected to your computer. Operations •...
-
Page 28: Service Window
Icon Meanings There are 3 states for the service icons, indicated by different colors. • White- Idle. The normal state. • Yellow- Available. The Bluetooth service is available on the selected remote device. • Green- Connected. The Bluetooth service is active in a connection with the remote device. Operations •... -
Page 29: Local Service Status
Local Service Status The local service status can be viewed from the Local Service Status dialog box. Right click whichever local service icon in service window and select the Status... on the pop-up menu. The Local Service Status dialog will be displayed. Figure1: Local Service Status (e.g. -
Page 30: Local Service List
Figure2: Local Service Status (PAN) Connection: Status: Whether the local service is connected. Device Name: Display the name of remote device which connects to the service. Duration: The time elapsed since the connection was set up. Connection List: Display the names and addresses of remote devices which connect to the PAN service. Local Service List The Local Service List displays all the Bluetooth services supported by the local computer. -
Page 31: View Menu
Icon Meanings There are 3 states for the local Bluetooth services, indicated by different icon colors. • White- Idle. The service has not been started. • Yellow- Started. The local Bluetooth service has been started. • Green- Connected. Some remote device has connected to the service. Operations •... - Page 32 My Bluetooth Menu • Bluetooth Device Discovery --- Search for other Bluetooth enabled devices in range. • Bluetooth Service Discovery --- Browse for the services of the selected remote device. • Security --- Configure the security setting of the local device (e.g. passkey requirement, data encryption, etc.).
- Page 33 Figure 3 Add Device From History • Configurations-> Quick Connect --- If desired, assign a remote device to automatically connect with whenever an application opens a specified Bluetooth serial port. (1) Assign: Assign a device to the selected port. (2) Remove: Remove the Auto-Connection device assignment for the selected port. Figure 4 Quick Connect •...
-
Page 34: Help Menu
Figure 5 Unplug HID Device • My Bluetooth Device --- Advanced hardware configuration, recommended for advanced users only. Please refer to Hardware Configuration for more details. Help Menu • Contents and Index --- Access BlueSoleil Online Help. • About BlueSoleil --- Information about your version of BlueSoleil. -
Page 35: Bluetooth Connection Management
Bluetooth Connection Management Bluetooth Connection Management includes: • Find Remote Devices • Connect and Disconnect • Connect via Shortcuts • Remote Device Status Find Remote Devices To set up a Bluetooth connection, the remote device must be found first. There are 3 ways to find remote devices in BlueSoleil. - Page 36 Disconnect Method 1: Select the remote device, right click the service button. On the popup menu, select Disconnect. Method 2: Right click the device icon. On the pop-up menu, select Disconnect | (the connection you want to disconnect). Method 3: For FTP and Synchronization connection, close the operation window, the connection will be disconnected.
- Page 37 Remote Device Status The remote device status can be viewed from the Remote Device Status dialog box. Right click the remote device icon and select the Status... on the popup menu. The Remote Device Status dialog box will be displayed. Figure 1 Remote Device Status DUN, FAX, SPP, and LAP.
- Page 38 Remote Device Properties The remote device? properties can be viewed from the Remote Device Properties dialog box. Right click the remote device icon and select the Properties... on the popup menu. The Remote Device Properties dialog will be displayed. Figure 1 Remote Device Property Dialog Device Name: The remote Bluetooth device's name.
-
Page 39: Device Configurations
Device Configurations The local device configurations include: • Local Device Hardware Configuration • Local Device Properties Configuration Hardware Configuration BlueSoleil supports the following kinds of Bluetooth radio adapters: USB, CompactFlash card (UART or BCSP). To access the hardware configuration screens, click Tools | My Bluetooth Device..., Bluetooth Device Select the type of Bluetooth enabled device that you plan to use, either a USB adapter or a CompactFlash (CF) card. -
Page 40: Properties Configuration
Properties Configuration To configure the properties of your local device, click My Bluetooth | Device Properties…, General • Device Name The local device's name, which will be shown to other Bluetooth enabled devices. • Device Type The device's type of your local computer (i.e., Desktop, Laptop or Server). •... - Page 41 Figure 2 Accessibility Properties Page Hardware View information about your Bluetooth hardware. • Manufacturer: The manufacturer of the local Bluetooth device. • HCI Version: The HCI version of the local Bluetooth device. • HCI Revision: The HCI revision of the local Bluetooth device. •...
-
Page 42: Security Configuration
Security Configuration Use the Security Configuration screens to specify the security settings of your local device, it includes: • General Security • Paired Devices Management • Local Services Security Pair / Un-pair Devices Once a remote device has paired with your computer by exchanging passkeys, passkeys will no longer be required for further connections between your computer and the device. - Page 43 Figure 1 Authorize Services Note: • The screen will only list the local services that require authentication. The local services that do not require authentication can be accessed freely. • The Authorization button is enabled only when the Security Level is set to Medium. Local Services Security To access the local services security configuration screen, click My Bluetooth | Security and click on the Services tab.
- Page 44 Local Services: • Authentication If checked, a passkey is required whenever a remote device attempts to connect with this service. • Encryption If checked, data transmitted between devices for this service will be encrypted. Authorization Button: Click to select the devices you wish to allow to use the selected service. In the Service Authorization screen, enter the following settings: •...
-
Page 45: Troubleshooting
When the program starts, the local device address is 00:00:00:00:00:00. Please check whether you have properly plug-in your Bluetooth USB dongle or Bluetooth CF card and whether the device is powered up. Bluetooth USB dongles can be detected automatically if they are in the IVT known device list (If you are using a device of a new model, please contact IVT so that the model can be added to the list). - Page 46 Can't find the remote device's services? First, please verify that whether the remote device is in connectable mode. If the remote device is set to non-connectable, other devices cannot connect to it. Second, please verify whether the remote device is within the radio range. Third, please check whether the remote device has connections already.
- Page 47 Bluetooth Connection Bluetooth functions are in the model of Client/Server. One Bluetooth device provides services, and another Bluetooth device uses these Bluetooth services. After connection, a Bluetooth link is set up between two devices, and the link is called a Bluetooth connection.
- Page 48 device will be asked to enter the same passkey as the one in your PC . Otherwise, the Bluetooth passkey is not asked. If authorization is set, the remote device has to be in the authorized devices list. If not, there will be a dialog to ask the user to confirm whether you are going to allow a remote device to use a services of the local device.
- Page 49 NAP (Networking Access Point) A network access point is a unit that contains one or more Bluetooth radio devices and acts as a bridge, proxy, or router between a Bluetooth network and some other network technology (10baseT, GSM, etc). Network address translation, which is used to re-map IP's from one address range to another range of network addresses.
