- Page 1 FILLING THE GAPS IN TECHNOLOGY Quick Start Guide Dec 2020 PATENT PENDING Rev. 0...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Definitions…………………………….…………………………………………………………...3 Safety Instructions…..………………………………………………………………………...4 Compliance Statements……………………………………………………………………..5 Contents………………………..…………………………………………………………………..6 Overview…………………………………………………………………………………………...8 Getting Started………………………………………………………………………………...10 Starting a Session……………………………………………………………………………..11... -
Page 3: Definitions
DEFINITIONS NOTE: A NOTE indicates important information that helps make better use of the FILLING THE GAPS IN TECHNOLOGY product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death. -
Page 4: Safety Instructions
CAUTION: Repairs may only be done by a certified service technician. End user should only perform troubleshooting and simple accessory/cable replacement as authorized in this product documentation, or as directed by the online or telephone service and support team. Damage due to servicing that is not authorized by WYLMAN is not covered under warranty. Read and follow the safety instructions that came with the product. CAUTION: Handle PEGASUS and accessories with care. Although PEGASUS enclosure is ... -
Page 5: Compliance Statements
COMPLIANCE STATEMENTS FCC Compliance Statement: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the ... -
Page 6: Contents
CONTENTS PEGASUS Power Supply HDMI Cable (6.6 ft) PEGASUS Shield DVI‐D Dual Link Video SVGA Cable (6 ft) Cable (6.6 ft) VGA to DVI Adapter USB 2.0 Cable (6.6 ft) - Page 7 CONTENTS USB Ethernet Adapter USB Wi‐Fi Adapter NOTE: If any of the contents is missing, please contact WYLMAN for support. NOTE: To ensure the maximum security for our customers, only the provided external network adapters will be accepted by PEGASUS.
-
Page 8: Overview
OVERVIEW... - Page 9 Keyboard, mouse, etc. It does not support using any type of storage read and/or write devices; USB flash drive, external disc drive, etc. 5. Network Port (RJ45) Optional wired network connection to connect to LAN and/or to the internet. 6. HDMI Output Optional video output, can be used for PEGASUS configuration and/or monitoring. 7. HDMI Input Optional HDMI input, can be used to receive video signal from Target computer. 8. DVI Input Optional DVI input/VGA input with the DVI‐VGA adapter (included), can be used to receive video signal from Target computer. 9. Keyboard & Mouse Port (Micro USB Type B) Used to transfer the Keyboard & Mouse Commands from PEGASUS to Target Computer. 10. Power Switch Used as the master on/off switch for PEGASUS.
-
Page 10: Getting Started
GETTING STARTED Initial configuration 1. Make sure the box include all contents mentioned. 2. Connect PEGASUS to its power supply. It is recommended to connect the grounding screw to a clean/instrument ground bus. 3. Connect a monitor to PEGASUS HDMI Output, monitor not included. 4. Connect Keyboard and Mouse to PEGASUS using the available USB 2.0 ports. 5. Power up PEGASUS. 6. Login screen will be displayed, “WYLMAN” is the default password. 7. After PEGASUS boots, log in as administrator, “WYLMAN” is the default password. 8. Detailed User Manual is available on the PEGASUS Shield USB Drive and available online at www.wylman.com NOTE: All passwords in the system are set to “WYLMAN” as default. It is strongly recommended to change the passwords on the first use and ... -
Page 11: Starting A Session
STARTING A SESSION Instructions below explain the needed connections to be able to start a View or a Control session: 1. Assign Target Machine, Activate PEGASUS and PEGASUS Shield. Refer to user manual for details. 2. Connect PEGASUS to its power supply. It is recommended to connect the grounding screw to a clean/instrument ground bus. 3. Connect video cable from Target machine to a PEGASUS video input. 4. Connect Target machine to PEGASUS keyboard and mouse port; this connection is required even if the session is a view only session. 5. If using wired connection to connect PEGASUS to LAN/internet, connect the ... - Page 12 © 2020 WYLMAN LLC. ALL RIGHTS RESERVED PATENT PENDING WYLMAN LLC TEL: +1‐832‐632‐4400 Email: support@wylman.com www.wylman.com...
