triOS 02A100 8 Series Quick Manual

Wiper W55 V2
Wiper W55 V2
02A100XX8
The TriOS Wiper W55 V2 provides an additional cleaning option for all TriOS photometers with path lengths
up to 10 mm. The wiper housing can be mounted on the sensor in just a few steps and provides reliable
cleaning of the measurement windows. The new magnetic axis lock allows quick and easy wiper blade re-
placement, without any tools.
The new version of the wiper now features blockage detection and removal, and a service mode that increas-
es the life of the wiper through regular use. The accessory can also be used in seawater up to a depth of 10m.
Technical Specifications
Path lengths
Control port
Trigger input
Power consumption
trigger input
Operating time (max.)
Dimensions L x Ø
Weight
Material
Power supply
Power consumption
Maintenance effort
Maintenance interval
Warranty
Max. Pressure
Protection Type
Inflow velocity
Operating temperature
Storage temperature
D04-067en202111 Quick Guide Wiper W55 V2
TriOS Mess- und Datentechnik GmbH · Bürgermeister-Brötje-Str. 25 · D-26180 Rastede · Germany
fon: +49 (0) 4402 69670 - 0 · fax: +49 (0) 4402 69670 - 20 · info@trios.de · www.trios.de
2 mm, 5 mm, 10 mm
4-pin M8-plug
A suitable M8 connection cable with open end is included in the scope of
delivery.
5-24 VDC (±10% )
2...15 mA
3 Seconds
175 mm x 80 mm
0.52 kg
NBR, POM, TPE (PP, EPDM), Titanium or V4A
12-24 VDC (± 10 %)
approx. 2-6 W in operation; max. 0.75 W in standby
≤ 0.5 h/month typical
depending on application
1 year (EU & USA : 2 years)
1 bar
IP68
up to 10 m/s
+2...+40 °C
-10 °C...+70 °C
