MAX power MPD877L Operating Manual page 2

1
12
2
11
10
3
9
4
8
5
7
6
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: 1) this device may not cause
harmful interference, and 2) this device must accept any interference
received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void your authority to operate the
equipment.
1.Mode selection(switch USB,
Micro SD,Radio,&AUX)
2.Standby
3.Play/Pause
4.Equalizer
5.Repeat
6.Number Selecton(0-9)
7.LED light on/off
8.Volume up
9.Volume down
10.Next
11.Previous
12.Mute
CONTROL PANEL FUNCTION DECLARATION
1 2 3 4
LED.SW
1.
2.
3.
4.Mode selecton(Single press USB,
Micro SD, Radio, & AUX; long press
LED light on/off)
5.Previous
6.Play/Pause(
BT: Long press for 3
seconds, BT docking)
TWS FUNCTION
1.Turn on two devices of the same model and switch the two devices to Bluetooth mode.
The distance between the two devices is less than 50CM.
2.The first time you use the TWS connection, you can select any device as the host
and the other as the slave. Press and hold the "Pause playback"
seconds,and the USB display flashes to indicate that Bluetooth is connected.
3.Until you hear a "beep" sound, the devices are connected to each other.
4.Turn on the Bluetooth on your device and connect to the MPD877L.the next two
speakers will automatically connect to each other.
5.Disconnect TWS: Press and hold the "
Once you hear a beep, the TWS function will be disconnected.
6.In the future use, each time the TWS connection is used, the device connected to
the first time is used as the host (the slave can disconnect the TWS and cannot
connect to the TWS), and the connection to the TWS must be completed in the host.
5 6 7 8 9 10 11 12 13 14
VOLUME
CHARGE
DC 5V
TWS
CHARGE LIGHT
POWER
Model: MPD877L
7.Next
8.
9.Micto SD
10.
11.The DC 5V power input
12.
13.The charging light is on, the
full light is off
14.
button for 3
Pause playback " button for 3 seconds.
