FSM ATLAS Assembly Instructions

WIRE SHELVING
ASSEM B LY INSTRUCTIONS
BOTTOM
OF POST
TAPERED
FOOT AND BUSHING
RUBBER FOOT_ ,
A
FOR USE AS FREE-STANDING,
STATIONARY SHELVING:
Before assembly, lay out storage area accord­
ing to desired configuration. "T", "U", configura­
tions may be used.
Insert tapered foot bushing into the bottom of
each post. Seat securely by tapping with a rubber
mallet. Screw the adjustable foot levelers into
each bushing. After assembly, stand unit upright
and adjust the foot levelers as required.
7
STEP 1.
6
First perform "A•, "B",
according to the style you have
selected. NOTE: Unit is erected
from the bottom shelf up. Posts
are grooved and numbered in 1"
5
increments. (Number shown is
approximate height of shelf from
floor not including casters.)
STEP 2.
4
Select the height of lowest shelf.
,
\
BOTTOM
LEVELING
OF POST
SCREW I
STEM CASTER
B
FOR USE WITH S TEM CASTORS:
Push swivel stem casters into bottom of
each post. Seat securely by tapping with a mallet.
(Note: tapered foot bushing and levelers are not
required when using stem casters.
STEP 5.
Stand lowest shelf on its side.
Insert posts from bottom into all
four corners so the split sleeves fit
inside each corner. Stand upright.
STEP 6.
At each corner, push shelf firmly
down onto split sleeve. If necessary
for a snug fit, tap corner lightly with
a rubber mallet.
STEP 7.
Select height on the next lowest
shelf. Repeat steps 3 and 4. from
the top of standing unit, slide shelf
onto post at all four corners so the
split sleeve fits inside each collar.
Repeat for remaining shelves.
(Castor diameter
101mm)
ASSEMBLY CAN BE CARRIED
OUT BY ONE PERSON, HOW­
EVER ESPECIALLY FOR THE
LARGER SIZE SHELVE � WE
RECOM MEND TWO PEuPLE.
49
SPLIT
SLEEVE
STEP 3.
Hold one half of split sleeve against post with
wider end down. Fit "ridge" inside the split sleeve
into groove and snap split sleeve on. Then snap on
the other matching half of the sleeve.
STEP 4.
Repeat Step 3 at the same height for each of the
three remaining posts.
'
SiW
&:llllll llilc:e 1915
WIDER
.-END
