Team Digital BlocD8 Quick Start Manual

TEAM DIGITAL
BlocD8
High Density Block Detector
> 8 block detectors
> Electrical isolation from the track
> No track voltage drop
> LED indicator for each block
> 8 outputs for external LEDs or relays
> Featuring "Smart" Programming
> LocoNet ® compatible
> Eight configurable routes
Description
The BlocD8 is an eight block occupancy
detector for DCC. It is particularly useful
where high density or centrally located
detection is desired. Yards and automatic
train control are some examples. It provides
complete isolation from the track by using
transformer type sensors. This also means
there is no drop in track voltage as there is
with sensing diodes. The BlocD8 is designed
to work well with the family of SIC24 Signal
and Indicator Controllers and the CSC
Central Signal Controller. The BlocD8 can be
in a stand-alone mode with using the output
connector or in a network with other devices
using the serial bus.
08.30.17
8
BlocD8
Status LEDs
Smart
1
button
Output connector
1
Improving the world of DCC
1
Track
Sensitivity
or
DC power
Serial bus
TEAM DIGITAL, LLC
3111 Timber Valley Dr
Kokomo IN 46902
www.teamdigital1.com
