- Page 1 TIENet ® Sampler Interface Installation and Operation Guide Manual Body #69-4303-072 Copyright © 2021. All rights reserved, Teledyne ISCO Revision E, May 2021...
- Page 3 Teledyne Isco recommends that you read this manual completely before placing the equipment in service. Although Teledyne Isco designs reliability into all equipment, there is always the possibility of a malfunction. This manual may help in diagnosing and repairing the malfunction.
- Page 5 TIENet® 306 Sampler Interface Safety TIENet™ 306 Sampler Interface Safety General Warnings Before installing, operating, or maintaining this equipment, it is imperative that all hazards and preventive measures are fully understood. While specific hazards may vary according to location and application, take heed of the following general warnings: WARNING Avoid hazardous practices! If you use this instrument in...
- Page 6 TIENet® 306 Sampler Interface Safety The equipment and this manual use symbols used to warn of Hazard Symbols hazards. The symbols are explained below. Hazard Symbols Warnings and Cautions The exclamation point within the triangle is a warning sign alerting you of important instructions in the instrument’s technical reference manual.
-
Page 7: Table Of Contents
2.5 Contact Teledyne Isco ........ - Page 8 TIENet 306 Sampler Interface Safety...
-
Page 9: Section 1 Introduction
TIENet devices, the TIENet Expansion Box is available. Bulk TIENet cable may also be used for greater distances. Figure 1-1 TIENet 306 with TIENet connector (t) and TIENet with wire connector (b) -
Page 10: Operation
1.1 Operation The Signature flow meter uses a 5-Volt pulse output to signal a connected Teledyne ISCO automatic sampler to collect flow paced samples. Based on user-defined conditions, the flow meter can signal the sampler to start (enable) or stop (disable). It also... -
Page 11: Connector Description
TIENet® 306 Sampler Interface Section 1 Introduction 1.2 Connector The 306 connects to the flow meter port of a Teledyne ISCO sampler with a 6-pin female, sealed plug. Description Note The ISCO 4700 and 5800 Refrigerated sampler also requires the adaptor cable that duplicates the ISCO sampler flow meter port. -
Page 12: Accessories
Bulk TIENet Cable (cut-to-length; order by the foot)............. 60-4304-050 4700/5800 Sampler interface adapter cable................60-5314-697 Note Teledyne ISCO uses FreeRTOS version 5.4.2 in its TIENet devices. In accordance with the FreeRTOS license, FreeRTOS source code is available on request. For more information, visit... -
Page 13: Section 2 Installation And Operation
TIENet 306 Sampler Interface ® Section 2 Installation and Operation 2.1 Installation External TIENet devices such as the 306 are all connected to the Signature Flow Meter in the same manner, usually using conduit or cord-grip cable fittings. Multiple external TIENet devices can be connected simultaneously. - Page 14 TIENet® 306 Sampler Interface Section 2 Installation and Operation 3. Feed the TIENet device cable end through the sealing nut and seal, and through the cable nut. Lightly tighten the sealing nut, just enough to hold the cable in place while installing the connector.
-
Page 15: Tienet Device Terminal Connections
TIENet® 306 Sampler Interface Section 2 Installation and Operation Shield Braid-Drain Figure 2-3 TIENet Device terminal connections 5. Press the terminal strip back down into its socket on the case board, as shown in Figure 2-5, taking care not to strain any wire connections. -
Page 16: Connecting To Signature Portable Via A Tienet Receptacle
TIENet® 306 Sampler Interface Section 2 Installation and Operation from entering the Signature enclosure. Failure to seal conduit could reduce equipment life. 8. Close the front panel and fasten it shut with the two Phil- lips screws. Figure 2-5 Position and secure the cable The optional external TIENet devices compatible with the Sig- 2.1.2 Connecting to nature Portable (and Signature) all scan into the hardware in the... - Page 17 TIENet® 306 Sampler Interface Section 2 Installation and Operation • 301 pH Interface • LaserFlow • 306 Sampler Interface Connecting a TIENet plug To connect the TIENet plug from the sensor to the TIENet Recep- to the Signature Portable tacle: 1.
-
Page 18: Connecting To The Sampler
Figure 2-7 Connecting to the sampler 2.2 Configuring the To configure the Signature flow meter for operation with a Interface sampler using the TIENet 306 device, press ) to MENU access the top menu, and select Hardware Setup. For all TIENet devices including the 306, select TIENet Setup (Smart Sensor). -
Page 19: Character Grid
TIENet® 306 Sampler Interface Section 2 Installation and Operation The name of any parameter can be customized by highlighting it and pressing Enter ( ) to display the character grid. Nav- igate the grid using the arrow keys. Select characters with Enter and clear characters with Delete ( 3 0 6 S a m p l e B o t t l e Done... - Page 20 TIENet® 306 Sampler Interface Section 2 Installation and Operation Select Operation 1. Hardware Setup 2. Configure 3. Administration 4. Home Hardware Setup 1. Smart Sensor Setup (TIENet) 2. SDI-12 Setup 3. MODBUS Input Setup 4. MODBUS Output Setup 5. Modem Setup With initial connection, begin TIENet Setup (Smart Sensor) by performing a hardware...
-
Page 21: Enable Settings
TIENet® 306 Sampler Interface Section 2 Installation and Operation 2.3 Enabling and Pacing The Signature flow meter can enable or disable the connected sampler with a signal based on a defined condition (such as level, the Sampler flow rate, pH, temperature, etc.) or combination of conditions. This is called a sampler Trigger. - Page 22 TIENet® 306 Sampler Interface Section 2 Installation and Operation Configure Options 1. Site Setup 5. Data Storage/Push Setup 6. Sampler Setup 2. Measurement Setup 3. Adjust 7. Inputs/Outputs/Alarms Setup 4. Equation/Trigger Setup 8. Reset Totalizers 9. Reports/History Setup Sampler Setup 1.
-
Page 23: Firmware Updates
Signature Flow Meter. Step-by-step instruc- tions for updating the firmware can be found in Section 2 of the Signature user manual. 2.5 Contact Teledyne If you have further questions about the installation, operation, and maintenance of your TIENet device, please contact our... - Page 24 TIENet® 306 Sampler Interface Section 2 Installation and Operation 2-12...
-
Page 25: Appendix A Replacement Parts
Replacement parts are called out in the following illustrations. Refer to the call-out in the adjacent table to determine the part number for the item. Replacement parts can be purchased by contacting Teledyne ISCO’s Customer Service Department. Teledyne ISCO Customer Service Department P.O. - Page 26 TIENet® 306 Sampler Interface REPLACEMENT PLUG SENSOR CAP KIT FOR 2100 SERIES AND TIENET DEVICES #609004469 O-RING (0.614 I.D., 0.070 CROSS SECTION) #202106016 PROBE CONNECTOR PLUG FOR 306 SAMPLER INTERFACE # 604303068...
- Page 27 TIENet® 306 Sampler Interface...
- Page 28 TIENet® 306 Sampler Interface...
- Page 29 Compliance Statements Name and amount of Hazardous Substances or Elements in the product Hazardous Substances or Elements Component Name (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) Circuit Boards Display Wiring Internal Cables DC Motor Connectors Battery Solenoid valve Name and amount of Hazardous Substances or Elements in the product O: Represent the concentration of the hazardous substance in this component’s any homogeneous pieces is lower than the ST/ standard limitation.
- Page 31 68504, U.S.A. customer’s facility and the repair facility. * This warranty applies to the USA and countries where Teledyne Isco does not have an authorized dealer. Customers in countries outside the USA, where Teledyne Isco has an authorized dealer, should contact their Teledyne Isco dealer for warranty service.
