AEBI Meyer Base Line 240 Series Original Owner's Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Original Owner's Manual

Base Line and Blaster

Table of Contents

Need help?

Do you have a question about the Meyer Base Line 240 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for AEBI Meyer Base Line 240 Series

Page 1 Original Owner's Manual Base Line and Blaster...
Page 2: Introduction
Introduction Introduction Meyer Products LLC has published this manual to help you get maximum performance WARNING: Deployment of an air bag while using a Meyer Spreader will not be covered under Meyer Products’ warranty. We also recommend that, for optimum performance, vehicles used for ice control from your Meyer Spreader and familiarize you with the features designed for effi ciency be equipped with: and safety;...
Page 3: Table Of Contents
Table of Contents Introduction .................................. 2 Warranty ..................................4 Registration .................................. 5 Safety Defi nitions & Warnings ...........................6-7 Safety Decals ................................8 Vehicle Requirements ..............................9 Base Line Component Identifi cation ..........................10-11 Receiver Mount ..............................12 Installation................................13 Controller ..............................14-15 Blaster Component Idenfi tication ..........................16-19 Receiver Mount .............................20-21...
Page 4: Warranty
Warranty Your operator's manual provides essential information on safety, operation, and maintenance. Failure to follow this operator's manual may result in damage to your equipment and affect your warranty. Base Line and Blaster spreaders are both covered under the Meyer warranty. •...
Page 5: Registration
Registration Once registered (Blaster only*), you will be provided with a registration ID. Meyer recommends completing the fi elds below for future reference. Registration ID ___________________________________ Purchase Date ___________________________________ Purchased From __________________________________ Model _____________________________________ Serial Number __________________________________________ * Only the Blaster model requires registration. Please retain proof of purchase and present to a Meyer dealer for proof of warranty on Base Line models.
Page 6: Safety Defi Nitions & Warnings
Safety Defi nitions & Warnings DANGER NEVER stand or ride on the spreader. Failure to comply will result in death or serious injury. DANGER Keep hands, feet, and clothing away from power driven parts. Failure to comply will result in death or serious injury. SAFETY DEFINITIONS Make sure spreader is completely shut off and all movement has stopped before attempting to clean, service or unclog.
Page 7 Safety Defi nitions & Warnings Gasoline is highly fl ammable and gasoline vapor is explosive. Never smoke while working on vehicle or spreader. Keep all WARNING open fl ames away from gasoline tank and lines. Wipe up any spilled gasoline immediately. Failure to comply will result in death or serious injury.
Page 8: Safety Decals
Safety Decals These safety alert decals are used to alert you of potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. DANGER Conveyor CAUTION This decal alerts all to the danger of serious This decal cautions all to observe general personal injury or death while servicing or safety procedures when operating,...
Page 9: Vehicle Requirements
Vehicle Requirements For installation Base Line 240 & 400 series spreaders: 1. This product line can be installed on any vehicle with a class 3 hitch receiver that will accept a 2" square tube and has a tongue weight rating of at least 500 lbs (227 kg). 2.
Page 10: Base Line
Base Line Component Identifi cation Base Line 240/400/750...
Page 11 Base Line Component Identifi cation Item Part No. Qty. Description Item Part No. Qty. Description 31101 • 240 Hopper 22728 • Set Screw 3/4-10 SS 36101 • 400 Hopper 20303 • Locknut 1/4 Esna 39102 • 750 Hopper 20313 • Locknut 5/16 Esna 31102 •...
Page 12: Receiver Mount
Base Line Receiver Mount CAUTION: Always disconnect battery before beginning installation. CAUTION: The spreader is a large heavy item that should be installed with an assistant. As with any new equipment installation read and understand all instructions prior to starting the job, and do not hurry through it. A correct installation now can save time and money later.
Page 13: Installation
Base Line Installation Choose a location for the Controller (30) that is convenient for the driver. Make certain Controller (30) is grounded by attaching ground wire to a good vehicle ground. Attach the eyelet end of the 96" (2.5m) red wire (34) to the positive terminal of the battery and route the plug end to the location of the speed control. DO NOT attach to Controller (30) at this time.
Page 14: Controller
Base Line Controller Installation The BL Controller is an electronic module powered off the switched ignition circuit +12Vdc and supplying the heavy motor current from the +12Vdc battery circuit. The controller will only function with the ignition key in the ON state. The controller is connected to the spinner motor and vibration motors via a custom wire harness that is designed to handle the high motor currents.
Page 15 Base Line Controller The controller will provide the spreader motor with multiple speed options per following: ON/OFF Depress the button once to enable the spreader motor operation. Spreader motor will automatically be activated with 5 full power Blasts and then stop. The GREEN LED located above this switch will illuminate. ON/OFF Depress the button a second time and the spreader motor operation will stop.
Page 16: Component Idenfi Tication
Blaster Component Identifi cation Blaster 350/350RS Note: 350S Auger Extension (16) must be removed when using salt only. If it is not removed this may cause the motor to stall.
Page 17 Blaster Component Identifi cation Item Part # Part # Qty. Description Item Part # Part # Qty. Description Item Part # Part # Qty. Description 32000 37000 Blaster Assembly 22726 22726 • Set Screw 5/16” SS 22731 22731 •• Hinge Pin w/ Clip 32100 32100 •...
Page 18 Blaster Component Identifi cation Blaster 750R/750RS Note: 350S Auger Extension (17) must be removed when using salt only. If it is not removed this may cause the motor to stall.
Page 19 Blaster Component Identifi cation Blaster 750R/750RS Item Part # Part # Qty. Description Item Part # Part # Qty. Description Item Part # Part # Qty. Description 33750 39010 Blaster Assembly 22725 22725 • Bolt 1/4-20 x 3/4” SS 22727 •...
Page 20: Receiver Mount
Blaster Receiver Mount The Blaster 350/350S/750R/750RS is a dedicated 2" receiver hitch mount salt spreader. Prior to installation, be certain that the vehicle receiver is in good working order, is rated for at least a 500 lb. (227kg) tongue load, and is fastened to the vehicle securely. CAUTION - The spreader is a large heavy item that should be installed with an assistant.
Page 21 Blaster Receiver Mount SAFETY PRECAUTIONS SAFETY PRECAUTIONS 22/23/24/25/27 5/9/11/12 SEE PAGES 6-7 FOR DEFINITIONS...
Page 22: Installation
Blaster Installation Locate the wire harness (38) and begin to route it from the rear of the vehicle to the front. The molded rubber plug indicates the rear of the harness, closest to the spreader. Use frame holes and frame supports as lashing points. Do not attach to fuel or brake lines. Avoid wire-runs along exhaust system or hot engine parts. Melting damage to the harness can occur in the proximity of extreme heat.
Page 23: Controller
Blaster Controller The controller is equipped with a power on switch, blast switch, vibrate switch and rotary speed control. Once the ignition key is turned to the ON position, the controller face plate will illuminate white indicating that the controller is ready for operation. During operation, face plate color will vary depending on the mode of operation and status of the controller. If the vehicle ignition is shut off while the controller power switch is in the ON or AUTO position the controller will turn off.
Page 24: Spreader Maintenance
Spreader Maintenance Maintenance requirements for the Spreader during the winter season are relatively simple. Periodically inspect for loose bolts and nuts. Inspect for improper ground, broken wires, frayed or cracked wire insulation. Replace as necessary. WARNING: Disconnect power to spreader before servicing. CAUTION: Do not attempt to service control unit.
Page 25: Spreader Troubleshooting
Spreader Troubleshooting If your spreader is not operating properly, take it to your local Meyer Products Distributor for maintenance or service. However, that is not always possible, so below on this page you will fi nd a troubleshooting guide, which can assist you in determining the problem. WARNING –...
Page 26: Spreader Calibration
Spreader Calibration LANE MILE CALIBRATION (US) DISCHARGE RATE (pounds discharged per mile) TRAVEL SPEED AND COMPUTATION MULTIPLIER Discharge per Control Shaft RPM Discharge per 5 mph 10 mph 15 mph 20 mph 25 mph 30 mph 35 mph 40 mph 45 mph Minute (lb) Setting...
Page 27 Spreader Calibration PARKING LOT CALIBRATION (US) DISCHARGE RATE (pounds discharged per square foot) (lbs. discharged per sq. ft.) Shaft Spread Discharge Discharge Control Spread Pattern sq. ft. 5 mph 10 mph 15 mph 20 mph 5 mph 10 mph 15 mph 20 mph Pattern per Auger...
Page 28: Base Line
Meyer ® Base Line Spreader Warranty ® Meyer Products, LLC, warrants to the original purchaser of Meyer brand products that they will be free from defects in materials or workmanship, with the exceptions stated below. No person is authorized to change this warranty or to create any additional warranty on Meyer products. This warranty runs for a period of one year from the date of purchase on any purchase of a complete BL Spreader Package.
Page 29 Meyer ® Base Line Spreader Warranty Meyer Products will repair any product that proves to be defective in materials or workmanship. In the event repair is not possible or practical (as determined by Meyer Products in its sole discretion), Meyer Products will either replace the product with a new product of similar model and price, or refund the full purchase price, as determined by Meyer Products. Customer must keep the complete BL Spreader Package serviced/maintained as recommended by Meyer Products.
Page 30: Blaster
Meyer ® Blaster Spreader Warranty ® Meyer Products, LLC, warrants to the original purchaser of Meyer brand products that they will be free from defects in materials or workmanship, with the exceptions stated below. No person is authorized to change this warranty or to create any additional warranty on Meyer ®...
Page 31 • Contact your local Meyer® or Aebi-Schmidt dealer from whom the product was purchased or to any authorized Meyer® or Aebi-Schmidt dealer. Transportation and freight charges prepaid when applicable. Only Meyer® and Aebi-Schmidt dealers are authorized to perform the obligations under this warranty. For the address and telephone number of the Meyer®...
Page 32: Ec Declaration Of Conformity
EC Declaration of Conformity The undersigned representing the manufactuer... Meyer Products LLC 18513 Euclid Ave Cleveland, OH 4412 herewith declared that product: HomePlow, WingMan, Drive Pro, Drive Pro Light Duty, Lot Pro, Lot Pro Light Duty, Road Pro 32, Diamond Edge 2, Super Blade, Super-V, Super-V2, Super-V3, Nite Saber III Lights, Nite Saber LED Lights, Base Line, Blaster, Crossfi re, Elite, MDV, Polyhawk is in conformity with the essential requirements of the following EC directives when subject to correct installation, maintenance, and use conforming to its (their) intended purpose, to the applicable regulations and standards, to our operation and maintenance manual.
Page 33 Notes...
Page 34 Notes...
Page 35 Notes...
Page 36 Meyer Products carries a full line of spreaders and other products including: Broadcast Spreaders Broadcast Spreaders Insert Hopper Insert Hopper Featuring an unprecedented ten-year If you are looking for a heavy-duty warranty on the virtually indestructible broadcast spreader for all-season use, polyethylene hopper, Meyer outlasts look no further.
