SubC Imaging Aquorea Mk3 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aquorea Mk3 and is the answer not in the manual?

Questions and answers

Related Manuals for SubC Imaging Aquorea Mk3

Summary of Contents for SubC Imaging Aquorea Mk3

  • Page 1 USER MANUAL...
  • Page 2 Support Engineered in Canada Contact support Installing TeamViewer for remote support Telephone Ensure the LAN functionality in TeamViewer is enabled (go to Extras > Options > General > Incoming LAN connections). Using TeamViewer over LAN allows +1 (709) 702-0395 for much faster operation and better quality. SubC recommends using a LAN connection whenever possible.

  • Page 3: Precautions And Maintenance

    Precautions and Maintenance Please read this manual carefully before setting up and using your unit. The electronic version of this document is the controlled copy. Therefore, all printed versions of this document are uncontrolled. SubC equipment is designed to work at various depth ratings on unmanned vehicles. Designs are tested to their full pressure rating. Production units are pressure-tested to a nominal rating to ensure no leaks.
  • Page 4 O-Ring Lubricant Best practices for assembling your system Greasing the Connector/Dummy Plug (ABOVE WATER - DRY MATE ONLY) Connectors must be greased with Molykote 44 Medium (or equivalent) before every mating. Check the MSDS for your type of o-ring lubricant before use.

  • Page 5: System Hookup

    System Hookup Best practices for assembling your system For the fundamentals of how to capture excellent underwater photos and detailed video, check out our Underwater Photography Guide: https:/ /issuu.com/subcimaging/docs/subc_underwater_photography_guide?fr=sZmI1MTI1MjM2MzM SubC products are designed to run in water. There is built-in thermal protection in our equipment, however, we cannot guarantee performance in air.

  • Page 6: Quickstart And Setup

    QUICKSTART AND SETUP...

  • Page 7: Required Components

    Select the Port for the RS485 device and 115200 Baud Rate. Set it to Append CR-LF and click OK. AC-DC power supply Plug MCIL5F cable into back of Aquorea Mk3. Plug the RS-485 connector into the DB9 of the MCIL5F whip. MCIL5F whip Plug the AC-DC power supply into the MCIL5F whip.
  • Page 8 PM: CC Camera + LED Separate Power Sources Updated: 2020-11-25 Aquorea LED Aquorea LED Rayfin LEGEND HD-SDI Analog Sync Signal RS485 RS232 Fiber ROV Power (15 - 28Vdc) 5Vdc Power Requirement BH Type Bulkhead Purpose Rayfin = 12Watts (max) 2x Aquorea = 48W or 120W Device Pin 3-5 (signals) (selectable) each...

  • Page 9: Control Api

    CONTROL...

  • Page 10: Led Control Api

    Electrical: CC LED Control API Updated: Production: JMH 2021-02-09 Mechanical: BL Comms Commands ~comms set driver baud:# Set baud rate of all controller ports. Can be an index from list below or literal baud Serial settings rate Baud Rate: 115200 0 = 9600 1 = 115200 Byte Size: 8...

  • Page 11: Device Commands

    Electrical: CC LED Control API Updated: Production: JMH 2021-02-09 Mechanical: BL Device Commands ~device print fault Prints all system faults and all presently asserted alarms ~device clear alarm Clears all asserted alarms ~device set lamp:### Sets lamp target value between 0-100% of the current limit ~device print lamp Prints the commanded lamp value between 0-100% of the current limit ~device set lamp target:### or ~device set lamp...
  • Page 12 Electrical: CC LED Control API Updated: Production: JMH 2021-02-09 Mechanical: BL Device and LED Commands ~deviceprint temperature Print the temperature of all system thermistors (see also ~sensor print temperature) ~device set current limit:#.## Set the current limit in Amps. Valid arguments are 2 and 5; Also responds with the lamp maximum command ~auxsetmaxoutput:### (0-100) ~device print current limit Print the current limit in Amps...

  • Page 13: Sensor Commands

    Electrical: CC LED Control API Updated: Production: JMH 2021-02-09 Mechanical: BL Sensor Commands ~sensor print status Print all sensor status information ~sensor print temp Print current temperature, the high and low records and the target temperature ~sensor print temp high Print the record high temperature ~sensor print temp low Print the record low temperature...
