- Page 1 Assembly and Operating Instructions max. 120 kg ~ 60 Min. 38 kg L 96 | W 67 | H 158 DU STEPPER PLUS.01.02 ~ 60 Min. 238 kg L 156 | W 233 | H 250 Art. No. DU-STEPPER PLUS DUKE STEPPER PLUS...
- Page 2 STEPPER PLUS...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console Display STORAGE AND TRANSPORT General Instructions Transportation Wheels TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Error Codes and Troubleshooting Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES... - Page 4 Dear customer, Thank you for choosing a Duke Fitness brand fitness equipment. Duke Fitness offers you fitness equipment that makes it easy to start exercising regularly, stay fit and lose weight. We want to help you to achieve your fitness goals quickly and sustainably and hope that your new fitness equipment will help you to do so.
- Page 5 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 6: General Information
GENERAL INFORMATION Technical Data LCD Display of Speed in km/h training time in min training distance calories burnt heart rate Resistance system: manual magnetic brake system Resistance level: Maxiumm stride length: 25.4 cm Stride height: 18 cm Stride width: 27 cm Flywheel mass: 7 kg Weight and Dimensions:... -
Page 7: Personal Safety
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 8: Set-Up Place
Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 9: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 10: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠... -
Page 12: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step 1: Assembly of the Stabilizers and the Covers Mount the front stabilizer (2) and the rear stabilizer (3) to the main frame (1) with four screws (4),... - Page 13 Step 2: Assembly of the Pedals Place one pedal plate (83) on each of the pedal welds (9R & 9L). Mount the pedals (10R & 10L) to their respective pedal weld (9R & 9L) with two screws (11), two washers (6) and two nylon nuts (12) on each side.
- Page 14 Step 3: Assembly of the Swing Rods Slide the long axis (49) through the connection at the top centre of the main frame (1). Mount the right swing rod (29R) to the right of the long axis (49) with one screw (33), one spring washer (32), one washer (31), one washer (30) and one wave washer (95).
- Page 15 Step 4: Assembly of the Handlebars Mount the left and right handlebars (34L & 34R) to their respective swing rod (29L & 29R) with two screws (35), two washers (36) and two nuts (37) on each side.
- Page 16 Step 5: Assembly of the Middle Handlebar Slide the mid handlebar weld (39) into the main frame (1). Mount the mid handlebar weld (39) to the main frame (1) with one screw (42). Mount the middle handlebar (86) to the mid handlebar weld (39) with four screws (87), four washers (36) and four nuts (37).
- Page 17 Step 6: Assembly of the Monitor and the Bottle Holder Connect the cables of the mid handlebar weld (80 & 96) to the cables of the monitor (41). ࣑ ATTENTION Make sure not to pinch the cables during the following step. Mount the monitor (41) to the mid handlebar weld (39) with two screws (84).
- Page 18 Step 7: Alignment of the Feet If the floor is uneven, you can stabilize the equipment by turning the setting screws under the main frame. Lift the equipment on the desired side and rotate the setting screws under the main frame. Rotate the screws clockwise in order to remove them and to raise the equipment.
-
Page 19: Operating Instructions
OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Console Display Scan Displays a different training value every six seconds Displays the remaining or elapsed training time (00:00 -99:59 min.) TIME Displays the current training speed (0 - 999.9 km/h) - Page 20 Displays the current heart rate ⚠ WARNING Your training equipment is not a medical device. The heart PULSE RATE rate measurement of this equipment may be inaccurate. Various factors can affect the accuracy of the heart rate measurement. The heart rate measurement serves only as a training aid.
-
Page 21: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑... -
Page 22: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 23: Error Codes And Troubleshooting
Eliminate sources of interference (e.g. Sources of interference in mobile phone, WLAN, lawn mower the room and vacuum cleaner robot, etc..) unsuitable chest strap Use a suitable chest strap (see RECOMMENDED ACCESSORIES). Wrong position of chest No pulse display strap Reposition chest... -
Page 24: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Display console Slide rails Lubrication of slide rails and moving parts... -
Page 25: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. -
Page 26: Ordering Spare Parts
The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Duke Fitness / Elliptical Trainer Model Name: Elliptical Trainer Stepper Plus Article Number: DU-STEPPER-PLUS... -
Page 27: Parts List
Parts List Name Spec Qty. Main Frame Front Bottom Tube Rear Bottom Tube Screw M8*55 Spring washer D8 Washer D8*Φ16*15*1.5 Feet Cap Adjust Feet Cap 9L/R Pedal Weld 10L/R Pedal Bolt M8*50 Nylon Nut M8 Axis Cap Slider Board Screw M6*45 Nylon M6 Round Tube Cap Screw... - Page 28 Screw M8*16 34L/R L&R Handlebar Bolt M8*40 Washer D8 Nut M8 Foam Mid Handlebar Weld Screw M8*55 Monitor Screw M8*40 Washer D8*Φ28*2 44L/R L&R Crank Axis 6203ZZ Screw M6*15 Mid Axis Belt wheel Long Axis Washer Φ21*Φ17.5*0.3 Snap Ring D17 Crank Cap Nut M10*1.25 Flywheel Axis...
- Page 29 Spring Screw M5*12 69L/R L&R Chain Cover 70L/R L&R Decoration Cover Decorative Strip Screw ST4.2*20 Screw ST4.2*12 Screw ST4.8*19 Screw ST4.2*20 Tension Control Tension Control Back Cover Screw M5*20 Belt Sensor Wire Washer Φ8.5*Φ19*2 Tube Pad Pedal Plate Screw M5*10 Washer D16 Middle Handlebar Screw M8*35...
-
Page 30: Exploded Drawing
Exploded Drawing STEPPER PLUS... -
Page 31: Warranty
WARRANTY Training equipment from Duke Fitness® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 32 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
-
Page 33: Contact
CONTACT TECHNICAL SUPPORT TECHNICAL SUPPORT & SERVICE TECHNICAL SUPPORT & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de ��... - Page 34 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store www.sport-tiedje.co.uk for home fitness equipment with currently over www.sport-tiedje.de/blog 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 www.facebook.com/SportTiedje web shops in the respective national language or have their desired equpiment assembled on...
- Page 35 Notater Notes...
- Page 36 DUKE STEPPER PLUS...
