Rack Enclosures
12, 18, 27, 35, and 42 Space Rack Enclosures
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCITONS
Private Label Exhibit
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT
CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE
MAY OCCUR!
Rack Enclosures
REDRFE12: 12 Space Rack – 135 lbs
REDRFE18: 18 Space Rack – 500 lbs
REDRFE27: 27 Space Rack – 750 lbs
REDRFE35: 35 Space Rack – 900 lbs
REDRFE42: 42 Space Rack – 1,100 lbs
V5
(Max Weight):
P1
Advertisement
Table of Contents
Related Manuals for REDATOM Space Rack 12
Summary of Contents for REDATOM Space Rack 12
- Page 1 Private Label Exhibit Rack Enclosures 12, 18, 27, 35, and 42 Space Rack Enclosures INSTRUCTION MANUAL MANUAL DE INSTRUCCIONES MANUEL D’INSTRUCITONS CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! Rack Enclosures (Max Weight): REDRFE12: 12 Space Rack –...
- Page 2 QUESTIONS? NEED HELP? PLEASE EMAIL info@redatomproducts.com DISCLAIMER – WARNING INFORMATION Disclaimer – RED ATOM™ has extended every effort to ensure to accuracy and completeness of this manual. However, RED ATOM does not claim that the information covers all installation and or operational variables.
- Page 3 PRODUCT COMPONENT PARTS Shelf Screws Rack Spacing Part Letter 12 Space 18 Space 27 Space 35 Space 42 Space Product Components Front Door Spilt Back Doors Side Panels Fan Panel * Castors Adjustable Feet 2U Blank 2U Shelf 5U Shelf Shelf Screws (extra) Keys * Fans are not thermally activated, please plug them into a switchable device.
- Page 4 OPEN/ LOCK DOORS Pull handle and rotate to open doors. Push handle to flush position to lock doors with included key. REMOVABLE/ LOCKABLE SIDE PANELS Side panels are removable and include locks for improved security. (note- included keys used to lock/ unlock front/ back doors and side panels)
- Page 5 ADJUSTABLE SHELVES Adjust Shelves to desired location Adjuse los estantes a la ubicación deseada Réglez les tablettes À la position dèsiree Shelves and blanks can be relocated within the rack enclosure rails. Rail attachments include spacing numbers for proper alignment. (note- heavy components should always be placed at the bottom of rack enclosure) Locate heavier components at bottom of Rack...
- Page 6 DOOR REMOVAL/ REVERSAL (OPTIONS) Options Opciones Options Door can be removed or reversed to open from opposite side of rack enclosure. (note- door will need to be rotated 180 degrees (flipped) to switch door orientation) WALL MOUNTING – REDRFE12 ONLY Mount REDRFE12 to wall using wall hinge.
- Page 7 VENTILATION FOR COMPONENTS Additional ventilation for bottom components Ventilación adicional para los componentes de fondo Ventiation supplémentaire pour les composants bas Do not obstruct the perforated hexagonal holes located at Edge of base and lower section of back doors and side panels.
- Page 8 WARRANTY INFORMATION § This warranty applies to US Residents who purchase from an authorized RED ATOM™ Dealer. RED ATOM are covered against defects in materials and workmanship for 5 years. RED ATOM will repair or replace the defective component or product, at its sole discretion. Failure to follow product care instructions from RED ATOM will result in void of warranty.
