Pack Contents
Carefully check the contents of
the box, which are:
n-ABLER unit
USB to PS/2 adaptor plug
Instruction booklet
Warranty card
If any items are missing please contact
your supplier immediately
n-ABLER is the most adaptable mouse
alternative on the market and is specifically
designed to address the needs of computer
users with motor skills difficulties, poor hand-
eye co-ordination or learning difficulties.
It is especially suitable for improving
access for children and young people with
some special educational needs, learning
difficulties, for those who's work entails long
periods of computer use and for older people
and others with movement impairment.
The large, high mass, free-running ball requires
only a light touch which, together with the
function buttons, makes for easy navigation,
INSTRUCTIONS
n-Abler Trackball
Product Description
selection and manipulation of objects on the
computer screen.
The 'n-ABLER' emulates a computer mouse
but, with fingertip control and the need
for only minimal hand movement, reduces
wrist and elbow fatigue, requires far less
effort and is less tiring. The symmetrical
design enables users to work with either
hand without having to angle the wrist, and
the unit can also be configured for 'left-
handed' operation. Its large, integrated hand
support/palm rest makes work posture more
relaxed and less strained.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the n-Abler Trackball and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pretorian n-Abler Trackball

  • Page 1 INSTRUCTIONS n-Abler Trackball Pack Contents Carefully check the contents of the box, which are: n-ABLER unit USB to PS/2 adaptor plug Instruction booklet Warranty card If any items are missing please contact Product Description your supplier immediately n-ABLER is the most adaptable mouse...
  • Page 2 Features • Rugged construction and ergonomic design • Large footprint for maximum stability • Symmetrical design allowing use with either hand • Integral wrist support to minimise fatigue • Easy ‘plug and play’ installation (no additional drivers required) • High mass, 63mm, free-running ball for easy cursor control •...
  • Page 3: Installation

    Compatibility The n-ABLER works with USB and PS/2 compatible computers. This includes the majority of Personal Computers (PCs), Apple Macintosh computers and Chromebooks. PS/2 sockets are circular with 6 pins, whereas USB connectors are rectangular with 4 pins. Installation USB (Preferred connection method) Having located an available USB socket, simply plug your n-ABLER into it.
  • Page 4: Getting Started

    Getting Started Refer to Figure 1 for an introduction to the various buttons and features of your n-ABLER. Single Axis Button This button is used to freeze movement in one axis allowing you to ‘home in’ to a position one axis at a time. Press the button once to give left-right cursor only movement.
  • Page 5 Speed Control (see Figure 2) This button allows the cursor speed to be changed to suit your personal preferences. Press the button briefly to change the speed. There are four speed settings to choose from. Once you have reached the fastest speed, pressing the button again will return the unit to the slowest speed.
  • Page 6: Learn Mode

    Learn Mode Step 1 Figure 3 Orientate your n-ABLER Begin with your n-ABLER unit in the intended operating position (1,2,3 or 4 as shown in Figure 3). Step 2 Put your n-ABLER into Learn Mode Press the Speed Control button at the rear of the unit and keep it pressed for three seconds until you hear a ‘warbling beep’...
  • Page 7 Step 3 Press the button you would like the Right Socket to function as For example, if you want the Right Socket to function as Speed Control, press the red Speed Control button (at the rear of the unit) once. Your n-ABLER emits a ‘warbling beep’...
  • Page 8: Maintenance

    Maintenance The ‘n-ABLER’ has no user serviceable parts. If repair is necessary the unit should be returned to Pretorian Technologies Ltd or an authorized distributor. Warranty The ‘n-ABLER’ is warranted for 24 months from the date of purchase against defects in manufacture, or component failure.
