Summary of Contents for Abode Outdoor Smart Camera
- Page 1 Outdoor Smart Camera User Guide May 13, 2020...
-
Page 2: Table Of Contents
Contents 1. Introduction 2. Application Overview 2.1. Parts Overview 2.2. Power Supply 2.3. LED Indicators 2.4. Equipment Required 2.5. Hardware Installation 2.6. Setup with App... -
Page 3: Introduction
PIR sensor is designed to give a typical detection range of 5 meters and has 105∘degrees viewing angle to the front. The doorbell functions either as a part of the Abode alarm system by connecting to an Abode security system Control Panel, or as a standalone device. Setup and remote access of OSC is performed via smartphone application developed by Abode Systems, Inc.. - Page 4 Side (DC-Powered Attachment) Side (AC-Powered Attachment) 1. Microphone 2. Lens 3. LED light ring 4. PIR sensor 5. Camera body 6. DC camera mount 7. Magnetic mount 8. AC doorbell mount...
-
Page 5: Power Supply
2.2 Power Supply The OSC uses 8~24V AC power or 5V DC power as its power source. For AC-Powered (Doorbell) Setup: Loosen the two screws on the back of the Doorbell Mount. Connect hardwired AC doorbell wires to the inputs on the mount and rescue screws. Install OSC Camera Body to the Doorbell mount by rotating the device 90 degrees to lock into place. -
Page 6: Equipment Required
Android version requirement: Android 5.1 or above. iPhone version requirement: iOS 9 or above. I f planning to use the OSC with your existing alarm system, an Abode security system • alarm panel is required – the panel must be registered a valid Abode user account. ... - Page 7 Mounting holes 8-24V wiring pins For DC-Powered (Security Camera) Setup: With the Corded Attachment unplugged from power source, rotate the Camera Body 90 degrees to lock into place on Attachment. Secure bottom security lock screws. Plug USB power cable into a 5V powered USB Type-A port to power camera, or plug USB power cable into included AC wall adapter.
-
Page 8: Setup With App
Abode mobile app. A smartphone with the Abode app installed is required to perform setup. Search for the app in Google Play or Apple App Store, type “abode” int the search bar, then download the application. - Page 9 Using OSC as standalone device does not require any other Abode security system panels. A smartphone with the Abode app installed is required to perform setup. Search for the app in Google Play or Apple App Store, type “abode” int the search bar, then download the application.
- Page 10 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
