Brunton Firelight User Manual

1) Important Safety Warnings (Prior to
using the Firelight)
For your own safety, it is vital that you read and understand
this manual before using the Firelight. Be sure to follow all
safety instructions every time the lighter is used. Failure to
follow the manual can result in property damage, serious
injury, or death. Make yourself familiar with all of the
lighter's parts and features before attempting to light it.
Keep this manual for future reference.
If you have any questions, please contact your retailer, or
call Brunton directly at (307) 856-6559
• Keep the Firelight out of the reach of children
•
Fill Firelight in well-ventilated areas only, and keep
away from sparks, flame, or any other heat source
•
When filled, Firelight contains flammable gas under
pressure: never puncture or expose to temperatures
above 120° F (49° C)
•
Make sure hands and Firelight are dry before igniting
•
Ignite Firelight away from face and clothing
•
Do not touch burner to any surface being lit
•
Never tamper with the Firelight; only adjust it by using
the controls provided
•
Keep Firelight lid closed when not in use
2) Filling the Lighter
1. Unscrew the LED from the bottom of
the Firelight (Fig. 1).
2. Set the flame adjustment near the
minus (-) sign.
3. Hold the unit upside down and insert
the butane refill canister's nozzle into
the Firelight's fuel inlet valve (Fig. 2).
4. Press down firmly on the nozzle for
a few seconds. When the fuel level
2.
is full, a small air bubble will be
visible in the lighter's fuel gauge
window.
5. Set flame adjustment to desired
level, and reattach LED unit.
NOTE: Never attempt to ignite
lighter during the refilling process.
3) Igniting the Lighter
1. Open the lighter's cap by pressing the cap release
button.
2. Press the ignition lever all the way down. A "click" will
be heard, and the coil should begin to glow.
3. If necessary, use the flame adjustment lever to increase
or decrease the flame height.
4. Release the ignition lever to extinguish the flame.
5. If the Firelight is not igniting properly, refer to the
"Additional Suggestions" toward the end of this manual.
4) Using the LED Light
1. To turn on the LED, twist the grooved
ring near the bottom of the Firelight in
a counterclockwise direction until the
light comes on (Fig. 3).
User Manual
1.
3.
2. Twist the ring clockwise to turn off the LED and secure
it to the lighter.
5) Replacing the LED batteries
1. Remove the LED unit from the
bottom of the Firelight (Fig. 1).
2. On the underside of the LED,
turn the U-shaped battery
bracket counterclockwise and
remove the old batteries.
3. Insert two new CR1220 batteries
into the compartment as shown
(Fig. 4).
4. Put the U-shaped bracket back
in place, and reattach the LED
unit to the lighter.
6) Additional Suggestions
•
For best lighter performance, use only premium butane
lighter fuel.
•
If possible, keep the Firelight above freezing, and carry
it close to your body in extremely cold weather. In low
temperatures, it may be necessary to warm the lighter
for a few seconds before igniting.
•
Do not touch the burner coil with any object.
•
The flame should extinguish immediately upon release
of the ignition lever. If the flame briefly continues to
burn after the lever has been released, move the flame
adjuster closer to the minus (-) sign.
•
At elevations above 4500' (1500m), turn the flame
adjuster closer to the minus (-) sign to improve ease of
ignition.
•
For long term reliability, use compressed air to keep the
chamber free of debris and carbon buildup.
•
IMPORTANT: International aviation regulations
strictly prohibit the shipping or carrying of butane
gas on all commercial airlines. Before taking the
Firelight on an aircraft, press in on the fuel inlet valve
with a ballpoint pen or other suitable object until all
butane gas has been released from the lighter. Check
with your airline for additional information.
7) Warranty Information
Brunton® warrants this lighter/LED light to be free of
defects in workmanship and materials for one year from the
date of purchase. Proof of purchase is required, and the
warranty is non-transferable. The warranty does not cover
damage caused by accident, misuse, abuse, or tampering. A
nominal fee will be assessed to repair such damage.
If you have any problems with your Firelight™, please return
it to your retailer or send it to Brunton at the address below.
Please contact us by phone or email to receive an RA#.
Shipping cost to Brunton is the purchaser's responsibility.
Brunton will pay return postage.
Brunton
Warranty Repair
620 East Monroe Avenue
Riverton, WY 82501-4997
LIMITS OF LIABILITY:
Brunton assumes no responsibility for any direct or
consequential damage, inconvenience, loss, or injury arising
from possession or use of these goods. This warranty gives
you specific legal rights, which may vary from state to state.
4.
