GREISINGER electronic GLMU 200 MP Operating Manual

Conductivity-transmitter

Advertisement

T14.0.0X.6C-02
1 Specification
Measuring range 1 (one of the following can be configured):
Conductivity
Resistivity
TDS
Salinity
Meas. range 2 Temperature:
Accuracy: (at nominal temperature = 25°C)
Measuring:
conductivity:
temperature:
Add. output signal:
Measuring cell:
Temperature compensation: non linear function, linear function (coefficient configurable) or none
Min-/Max-Value Memory:
Output signal:
Scaling:
Connection:
for option AV01, AV10:
Auxiliary energy: (supply voltage) Uv = 12 - 30 V DC (4-20mA)
Reverse voltage protection: 50V permanent
Perm. impedance (at 4-20mA): R A (Ohm) < ( (Uv - 12V) / 0.02A )
Permissible load (at 0-...V): R L (Ohm) > 3000 Ohm
Adjusting:
Display:
Ambient conditions for electronics:
Nominal temperature:
Operating condition:
Storage temperature:
Ambient of standard measuring cell -5 to 80°C (short time up to 100°C)
Housing:
Dimensions:
Mounting:
Mounting distance:
Electrical connection:
EMC:
GREISINGER
Operating Manual for conductivity-transmitter
GLMU 200 MP
Range (rAnG)=0
0.0 ... 200.0 mS/cm
5.0 ... 100.0 Ohm·cm
-
0.0 ... 70.0
-5.0...140.0 °C (resolution 0.1°C or 0.1°F, NTC10k)
Attention: Consider application range of measuring cell: 0..80°C
±0,5% of measured value ±0,3 FS
±0.1°C of measured value ±1 Digit
±0.2 % FS
4 electrode measuring cell with temperature sensor NTC10k,
7 pole connector
Cell constant K: 0.45..0.65, determined and adjusted ex works
Min and max measured values are stored
refer to type plate, freely scaleable
By entering display values for 4mA (or 0V) and 20mA (or 1V/10V) output
4 - 20 mA (2-wire) – output signal electrically isolated
0 - 1 (10) V (3-wire) – output signal electrically isolated
Uv = 12 - 30 V DC, max. 10mA (0-1V)
or refer to type plate
Example: for Uv = 18V: R A < (18V - 12V) / 0.02A
via keypress. Conductivity by editing cell constant K (CELL)
Temperature by offset and scale.
approx. 10 mm high, 4-digit LCD-display
25°C
-25 to 50°C, 0 to 95 %RH (non-condensing)
-25 to 70°C
ABS (IP65)
82 x 80 x 55 mm (without elbow-type plug and sensor tube)
With holes for wall mounting (in housing - accessible after cover has been removed).
50 x 70mm, max. shaft diameter of mounting screws is 4 mm.
elbow-type plug conforming to DIN 43650 (IP65),
max. wire cross section: 1.5 mm², wire/cable diameter from 4.5 to 7 mm
In accordance with EN61326 +A1 +A2 (appendix A, class B), additional errors: < 1% FS.
When connecting long leads adequate measures against voltage surges have to be taken.
The electrode connections have to be protected sufficiently against ESD pulses, if the
device is used in areas with risk of ESD.
Range (rAnG)=1
Range (rAnG)=2
0.00 ... 20.00 mS/cm
0 ... 2000 µS/cm
50 ... 1000 Ohm·cm
0.50 ... 10.00 kOhm·cm
-
0 ... 2000 mg/l
-
Uv = 18 - 30 V DC, max. 10mA (0-10V)
electronic GmbH
Range (rAnG)=3
0.0 ... 200.0 µS/cm
5.0 ... 100.0 kOhm·cm
0.0 ... 200.0 mg/l
-
-
=> R A < 300 Ohm
