CH20M12
Selection-Tool
Instructions
Stand: 03.02.2010
How to use the Selection Tool
=> Selection
You have two options to select all parts you need for a complete CH20M-Housing
=> Click the picture of the individual items to go directly to the article list
=> Click "Start" to go to the Base elements and start your selection
=> Navigation
To navigate to the other article-pages you can click the icons on the bottom or the navigation arrow in the
headline.
.
=> Shopping-Basket
You have the opportunity to note your order-quantities for each article you choose.
These data will be recorded in the shopping basket (last page). You can print the shopping-basket for your reference.
=> Push the "Start Tool"-Button on this page to begin
Housing Width:
12.5 mm
Start Tool
