SOLARCHARGER SE-1500
register your warranty on line – www.sunsei.com
IMPORTANT! Please read the instructions before operating.
• When working around batteries and other electrical equipment, please observe industry standard and manufacturer's
safety procedures.
• Make connections in a well-ventilated area free from flammable gases or vapors.
• For 12V systems, ALL connections should be in PARALLEL: Positive (+) to Positive (+), Negative (-) to Negative (-).
• DO NOT attempt to recharge NON-RECHARGEABLE batteries.
• Always CONNECT the charge controller to the battery FIRST.
• When disconnecting your solar panel DISCONNECT the battery LAST.
Components in the package
Two (2) wire twist connectors
Stainless mounting screws (4)
Extension power cable (10ft.)
Battery clamp wire (1.5ft.)
O-ring connector wire (1.5ft.)
Female 12V socket cable (1.5ft.)
Male CLA adapter cable (1.5ft.)
Panel-to-panel jumper cable (1ft.)
1- Test
Press the sun-shaped button. The LED will light up when the panel receives sufficient
daylight to produce power.
2- Mounting
Press the sun-shaped button. The LED will light up when the panel
receives sufficient daylight to produce power.
3- Battery Connection
Position the solar panel where you would like it to be permanently
installed. Angle the panel in such a way that it will be perpendicular
to the strong midday sun (straight up in most cases), between 10
a.m. and 2 p.m. Insert each mounting screw and tighten carefully. Do
not over-tighten.
4- Optional Multi-panel
Note: Remove the connector caps before connecting the cables.
First, connect the GREY plug of the 10-foot extension cable to the
connector of the solar panel. Connect the cable of your choice to the
battery. (see FIG. 4). Finally, connect the other end of this cable with
the BLACK plug of the extension cable.
