Page 1 DESIGNED BY METRICA ASSEMBLY INSTRUCTIONS...
Page 2 THANK YOU FOR PURCHASING SP01, WE HOPE YOU ENJOY YOUR FURNITURE FOR MANY YEARS TO COME. THE SAFETY OF OUR PRODUCTS IS VERY IMPORTANT TO US, AND WE ENCOURAGE YOU TO ALWAYS FOLLOW ASSEMBLY INSTRUCTIONS AND SAFETY WARNINGS CAREFULLY. PLEASE BE AWARE THAT SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM FURNITURE TIP-OVER.
Page 3 DISCLAIMER THE ASSEMBLY INSTRUCTIONS ARE TO BE USED AS A GUIDE SHOWING THE CONCEPT OF THE SYSTEM. IT WILL NOT BE EQUAL TO THE SYSTEM YOU HAVE PURCHASED. ENSURE THAT ALL STEPS ARE FOLLOWED IN THE CORRECT ORDER AND THAT NO STEP IS LEFT OUT. A MINIMUM OF TWO PEOPLE ARE REQUIRED FOR ASSEMBLY.
Page 4 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 1 SHORT METAL BASE 1000 + STORAGE ELEMENT 1560X420 EXAMPLE SETTING 2 MEDIUM METAL BASE + MEDIUM WOOD TOP + 560X560 STORAGE ELEMENT + INTERNAL METAL SHELF FOR 560 CONTAINER + 1060X240 STORAGE ELEMENT p.
Page 5 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 1 PACKAGING BENCH PARTS BOX WITH METAL BASE AND HARDWARE BOX WITH 1560X420 STORAGE CONTAINER 2/3 WALL BRACKETS, 2 PLASTIC COVER, 2 METAL COVER, 6 SCREWS, SMALL SCREW DRIVER 2 HAND SCREWS (NOT REQUIRED FOR ASSEMBLY OF COMPOSITIONS WITHOUT WOODEN TOP)
Page 6 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 1 REMOVE THE METAL STRUCTURE FROM ITS PACKAGING AND PLACE IT ONTO THE FLOOR. BEFORE PLACING THE STORAGE CONTAINER ON TOP, MAKE SURE THAT THE ADJUSTABLE FEET ARE LOOSENED.
Page 7 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 1 REMOVE THE STORAGE ELEMENT FROM ITS PACKAGING AND PLACE IT ON TOP OF THE METAL STRUCTURE. ALIGN THE HOLES ON THE BOTTOM WITH THE HOLES OF THE METAL STRUCTURE. p.
Page 8 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 1 IF YOU WISH TO FIX THE COMPOSITION TO THE WALL, TAKE OUT THE PROVIDED METAL BRACKETS FROM THE PACKAGING. THE METAL BRACKET MUST BE FACING THE WALL. FROM UNDERNEATH, PLACE THE METAL BRACKETS UNDERNEATH THE METAL STRUCTURE AND FIX EVERYTHING WITH THE PROVIDED HARDWARE.
Page 9 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 1 POSITION THE BENCH AND FIX IT TO THE WALL USING PROVIDED METAL BRACKETS AND ADEQUATE HARDWARE (NOT SUPPLIED). p. 9 ©...
Page 11 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 2 PACKAGING BENCH PARTS BOX WITH WOODEN TOP BOX WITH METAL BASE AND HARDWARE 18 SCREWS 2/3 WALL BRACKETS p. 11 ©...
Page 12 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 2 PACKAGING STORAGE CONTAINER AND METAL SHELF BOX WITH 560X560 BOX WITH METAL BOX WITH 1060X240 STORAGE CONTAINER SHELF FOR 560X560 STORAGE CONTAINER CONTAINER 1 PLASTIC COVER,...
Page 13 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 2 BENCH ASSEMBLY REMOVE THE WOODEN TOP FROM ITS PACKAGING AND PLACE IT ON A CLEAN AND SOFT SURFACE/ BLANKET WITH THE HOLES FACING UP. REMOVE THE METAL STRUCTURE FROM ITS PACKAGING AND PLACE IT WITH THE ASSEMBLY BARS ONTO THE WOODEN TOP.
Page 14 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 2 BEFORE PLACING THE ASSEMBLED BENCH INTO ITS POSITION, MAKE SURE THAT THE ADJUSTABLE FEET ARE LOOSENED. ADJUST THE FEET IN ORDER TO ALIGN THE BENCH AND TOP HORIZONTALLY. POSITION THE BENCH AND FIX IT TO THE WALL USING PROVIDED METAL BRACKETS AND ADEQUATE HARDWARE (NOT SUPPLIED).
Page 15 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 2 IF YOU WISH TO HAVE AN INTERNAL METAL SHELF, PLEASE MAKE SURE TO ASSEMBLE THE SHELF BEFORE ASSEMBLING THE STORAGE CONTAINER ONTO THE BENCH. IT IS RECOMMENDED TO ASSEMBLE THE METAL SHELF UPSIDE DOWN, SINCE OTHERWISE THE METAL SHEET COULD BEND OR FALL DOWN DURING ASSEMBLY.
Page 16 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 2 EVERY BOX COMES WITH ONE PLASTIC AND ONE METAL COVER FOR EACH CABLE MANAGEMENT HOLE. FIX THE CABLE MANAGEMENT COVER EITHER IN- OR OUTSIDE THE BOX; YOU CAN CHOOSE WHICH ONE YOU WANT INTERNALLY AND WHICH ONE EXTERNALLY DEPENDING ON YOUR NEEDS.
Page 17 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 2 30MM POSITION THE STORAGE CONTAINER ONTO THE BENCH MAKING SURE THAT THE ASSEMBLY HOLES ARE FACING DOWN. WITH A TAPE MEASURE, MAKE SURE THAT THE STORAGE BOX PULLS OUT 30MM FROM THE BENCH; THIS HELPS TO FIND THE HOLES TO ASSEMBLE USING PROVIDED HAND SCREWS.
Page 18 S P Ø 1 D E S I G N . C O M YEE STORAGE SYSTEM EXAMPLE SETTING 2 EVERY BENCH COMES WITH TWO HAND SCREWS WHICH SHALL ALWAYS BE FIXED IN A DIAGONAL POSITION. FIX THE STORAGE BOXES WITH THE PROVIDED HAND SCREWS. p.
