MANUAL / SAFETY NOTES
FOR YOUR E-BIKE VISION POWERPACK, COMPATIBLE TO
GAZELLE INNERGY (PURE / XT / ORANGE / CHAMONIX / FUENTE / BALANCE / MISS GRACE)
DRIVE SYSTEM WITH 36 V
Power information
10,4 Ah / 378 Wh downtube and carrier version
13,6 Ah / 490 Wh downtube and carrier version
11,4 Ah / 416 Wh downtube and carrier version
382,4 x 121,4 x 71,5 mm
Date March 2019
Version 06
Akku Vision - Manual PowerPack for Gazelle
*Gazelle and Innergy are trademarks of the Koninklijke Gazelle N.V. NL
S. 1 / 10
Advertisement
Table of Contents
Related Manuals for Akku Vision E-Bike Vision POWERPACK
Summary of Contents for Akku Vision E-Bike Vision POWERPACK
- Page 1 Untergasse 5, D-63688 Gedern Tel. +49 6045 952520, www.accu-24.de MANUAL / SAFETY NOTES FOR YOUR E-BIKE VISION POWERPACK, COMPATIBLE TO GAZELLE INNERGY (PURE / XT / ORANGE / CHAMONIX / FUENTE / BALANCE / MISS GRACE) DRIVE SYSTEM WITH 36 V Power information...
-
Page 2: Table Of Contents
+49 (0) 6021 3289288 Email: info@akkuvision.de Web: www.akkuvision.de E-Bike Vision is a trademark of the Akku Vision GmbH Date March 2019 Akku Vision - Manual PowerPack for Gazelle S. 2 / 10 Version 06 *Gazelle and Innergy are trademarks of the Koninklijke Gazelle N.V. NL... -
Page 3: Introduction
Vision products invoiced value, as far as this is permitted by law. This does not apply, if a liability according to binding legal rules due to intent or gross negligencem has to be respected. Furthermore, the Akku Vision GmbH assumes no responsibility for the completeness and accuracy of the documents that come with the battery, due to its different distribution channels. -
Page 4: Ce Declaration Of Conformity
E-Bike Vision charger for PowerPacks with 36 V and a charge current of 4 A. • These allows easy charging directly on the eBike in no time. Date March 2019 Akku Vision - Manual PowerPack for Gazelle S. 4 / 10 Version 06 *Gazelle and Innergy are trademarks of the Koninklijke Gazelle N.V. NL... -
Page 5: Common Safety Notes For Powerpacks
The covers of charge/discharge connectors must be replaced immediately on loss, otherwise warranty void. • That way, you do have the maximum saftey! Date March 2019 Akku Vision - Manual PowerPack for Gazelle S. 5 / 10 Version 06 *Gazelle and Innergy are trademarks of the Koninklijke Gazelle N.V. NL... -
Page 6: Safety Notes For Charging
Connect the charger only to a suitable mains supply. • Do not charge NiCd, NiMh or primary cells! • Use the charger only with the appropriate PowerPacks of Akku Vision! • When not using for a longer period, disconnect the mains supply and also connected batteries. •... -
Page 7: The Charging
80 – 96 % charged capacity LED 1,2,3,4 and 5 lighting: >= 97 % charged capacity Date March 2019 Akku Vision - Manual PowerPack for Gazelle S. 7 / 10 Version 06 *Gazelle and Innergy are trademarks of the Koninklijke Gazelle N.V. NL... -
Page 8: Charging Time
You installed your new E-Bike Vision PowerPack correctly in your eBike and locked it (do not forget to remove the key)? Then turn on the drive system by the capacity indication button or via the ON /OFF switch of your HMI. The drive system now read the current capacity of the battery and will calculate the approximated range, based on your previous driving profile. -
Page 9: Lighting / Rear Light
For connecting the wires tot he rear light, please pay attention of right polarity. This is printed on the rear light. Red wire has to be connected to + and the black wire has to be connected to -! Date March 2019 Akku Vision - Manual PowerPack for Gazelle S. 9 / 10 Version 06... -
Page 10: Maintenance
Is the green LED of the charger flashing? If this is flashing red, there can be a short circuit. Charger and battery must be returned to the Akku Vision service center. If the battery is damaged, defective or exits any liquids or smell? Please do not use your PowerPack further and contact your dealer or our service center.
