- Page 1 Airflo MANUFACTURING CO., INC. 365 UPPER OAKWOOD AVE, ELMIRA NY 14903 PHONE: 607-733-8284 / FAX: 607-733-0587 OPERATOR & PARTS MANUAL PSV-8L ELECTRIC SPREADER Visit our website at www.air-flo.com...
-
Page 2: Table Of Contents
OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. Pre-Use Checklist Contents Read this entire Owner’s Manual Pre-Use Checklist ..........1 before attempting to operate or Vehicle Requirements ........... 2 install the spreader. o To avoid overloading the sander Spreader and Material Weights ....... -
Page 3: Vehicle Requirements
OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. Figure 2. Figure 4. Figure 3. Figure 5. Vehicle Requirements The spreader must be mounted on a ¾ to a 1 ton pick-up above 8500 # GVWR. CAUTION Do not overload the vehicle beyond its GVWR or GAWR. -
Page 4: Spreader And Material Weights
OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. Spreader and Material Weights MATERIAL WEIGHT (POUNDS PER CUBIC YARD) PSV-8E 650 lbs. #1 Rock Salt 950 lbs. #2 Rock Salt 1,215 lbs. Coarse Sand-Dry 2,565 lbs. Coarse Sand- Wet 3,240 lbs. -
Page 5: Installation Instructions
OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. Bill of Materials Installation Instructions Mounting the Spreader onto the Vehicle 1. Install the inverted “V” in the spreader using the 3/8 - 16X 1” hex bolts, 3/8” nuts, and 3/8” washers provided. -
Page 6: Things To Know After Mounting The Spreader
OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. Things to Know after Mounting the Spreader A. The tie-down straps are provided for the purpose of securing the spreader to the vehicle only and are not to be used for any other purpose. - Page 7 OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. 3. Adjust the tension of the roller chain by loosening the Pillow Block Bearings that are supporting the Spinner Shaft. Move the shaft either towards or away from the Motor Sprocket to adjust the tension.
-
Page 8: Spreader Maintenance
OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. Spreader Maintenance 1. Use dielectric grease on all electrical connections before an electrical connection is made or after a connector is disconnected. 2. Grease the following: a. Idler Shaft Bushings (2) Figure 13. - Page 9 OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. b. Motor to Conveyor Shaft Drive slide the pillow blocks in the Chains-Adjust the chain tension for desired direction. the sprocket assembly which 6. Empty the spreader of all snow...
-
Page 10: Part List
OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. Part List Spinner/Chute Assembly P a g e... - Page 11 OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. 28. Spring 10,036 27. Roll 19,029 26. Pin 24. Spinner 51,143 Motor Power Harness 07262 25. Conveyor Motor Power Harness 07261 10 | P a g e...
- Page 12 OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. 33. Top Drive Chain 04015 34. Middle Drive Chain 04016 35. Lower Chain Drive 04017 11 | P a g e...
- Page 13 OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. 12 | P a g e...
- Page 14 OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. Chute Body with 12 Inch Extension 13 | P a g e...
-
Page 15: Hopper Assembly
OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. Hopper Assembly 14 | P a g e... -
Page 16: Material Spreader Warranty
OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. MATERIAL SPREADER WARRANTY AIR-FLO MANUFACTURING CO., INC., hereinafter referred to as “Manufacturer”, warrants each new material spreader sold by the manufacturer to be free from defects in material and workmanship, under normal use and service, for a period of One (1) year after the date of delivery to the original retail purchaser, and Manufacturer will, at its option, replace or repair, at one of the Manufacturer’s Dealers, or at a point designated by the Manufacturer, any part or... - Page 17 OPERATORS MANUAL – PSV-8L (ELECTRIC) AIR FLO MANUFACTURING., CO INC. OPERATORS MANUAL-PSV-8L (ELECTRIC) REVISION HISTORY REVISION REVISION PAGES DESCRIPTION OF REVISION LEVEL DATE REVISED 16 | P a g e...
