Please hand out this manual to the final user.
MULTI-DRYER
Thank you for purchasing the Multi Dryer.
◆
◆
Check the name plate to see if the model, product number, and voltage are the same as the one
１．Installation
２．Piping
３．Power supply
４．Intermittent operation
５．Each abnormality indication
６．Filter replacement
７．When using as a shoulder type
８．Maintenance and inspection
Warranty
●Please be sure to read before use.
you ordered.
KANSAI ELECTRIC HEAT CORP
保存用
ＨＡＳ series
MANUAL
The contents of this instruction manual are
subject to change without notice.
In addition, the figures and indications in the
instruction manual do not guarantee the actual
specifications. It is prohibited to modify or copy this
instruction manual without the permission of the
manufacturer.
Advertisement
Table of Contents
Summary of Contents for kansai HAS Series
- Page 1 In addition, the figures and indications in the ８．Maintenance and inspection instruction manual do not guarantee the actual specifications. It is prohibited to modify or copy this instruction manual without the permission of the Warranty manufacturer. KANSAI ELECTRIC HEAT CORP...
-
Page 2: Installation
１．Installation ① Install it in a horizontal position. ② Please fix it firmly if necessary. ③ Places that cannot be installed or used ・ ・ ・ Place with vibration Top of fever Places exposed to wind and rain outdoors ・ ・... -
Page 3: Intermittent Operation
※Please make changes with the external ４．Intermittent operation operation function turned off. ● When the temperature of the constant temperature bath is controlled using an external sensor, the multi- dryer is stopped when the temperature inside the constant temperature bath reaches the set temperature, and the temperature inside the tank is -5 °... - Page 4 Press the hot air switch 8 times. ⑤ ⑥ Press the hot air temperature up key once to turn the set temperature display to "ON". "PAo" is displayed in the hot air temperature section, and "oFF." Is displayed in the set temperature section. Press the hot air switch once to display "SP1"...
- Page 5 ５．Each abnormality indication When the multi-dryer is abnormal, the details of each abnormality are displayed and the operation is stopped (only the ● internal temperature abnormality is in the ventilation operation state). Be sure to remove the abnormality and then restart the operation by turning on the power switch again.
- Page 6 ⑩ ⑪ ⑫ Internal temp sensor minus EXTERNAL SONSOR BURNOUT EXTERNAL SONSOR MINUS DISPLAY display （OPTION） （OPTION） When the external sensor temp drops When the internal temp sensor temp drops if the external sensor is disconnected, the below -15℃, the abnormal lamp (red) below -5℃ｔhe abnormal lamp (red) flashes, "- abnormal lamp (red) lights up after the hot air flashes, "----"...
-
Page 7: Filter Exchange
６．Filter Exchange ● Replace the filters of the multi-dryer HAS-17T to 47T as the outlet air volume decreases. The replacement filter is stored inside the muffling box (5 sheets are included at the time of shipment). 《THE WAY OF FILTER EXCHANGE》 ②... -
Page 8: Maintenance And Inspection
： Never perform an insulation withstand voltage test on this machine (already done at the time of shipment). It may cause a malfunction. HOT AIR GENERATOR KANSAI ELECTRIC HEAT CORP manufact urer 5-CHOME 4-18, TAKAIDANISHI HIGASHIOSAKA CITY OSAKA 577-8566 JAPAN PHONE (06) 6785-6001㈹ FAX (06) 6785-6002...
