Assembly Instructions
Customer Service
US: 1-800-645-2986
WINDOW AIR CONDITIONER
293079 - Window Air Conditioner 18,500BTU Cool 16,000BTU Heat, 208/230V
293080 - Window Air Conditioner w Heat 25,000BTU Cool 16,000BTU Heat 208/230V
293081 - Casement Window Air Conditioner 8,000BTU Cool, 115V
293082 - Casement Window Air Conditioner 10,000 BTU Cool 115V
Instrucciones de Ensamblaje
Servicio de atención al Cliente
US: 1-800-645-2986
REMOTE CONTROL
globalindustrial.ca
Directives d'assemblage
Service à la clientèle
Canada: 888-645-2986
Read this manual thoroughly prior to
installation, operation or maintenance.
Keep these instructions in a safe
location for future reference. For
questions, visit globalindustrial.com or
co
contact Customer Service at
1-800-645-2986.
User's Manual
TM
Advertisement
Summary of Contents for Global Industrial 293079
- Page 1 Canada: 888-645-2986 WINDOW AIR CONDITIONER REMOTE CONTROL 293079 - Window Air Conditioner 18,500BTU Cool 16,000BTU Heat, 208/230V 293080 - Window Air Conditioner w Heat 25,000BTU Cool 16,000BTU Heat 208/230V 293081 - Casement Window Air Conditioner 8,000BTU Cool, 115V 293082 - Casement Window Air Conditioner 10,000 BTU Cool 115V Read this manual thoroughly prior to installation, operation or maintenance.
- Page 3 IMPORTANT: Thank you for your purchase. Please read this manual carefully before operating. Make sure to save this manual for future reference.
-
Page 4: Table Of Contents
TABLE OF CONTENTS CONTINUED Remote Control Specifications ...................... Handling the Remote Control ......................Remote Functions ......................... Remote Display Icons ........................Operating Instructions ........................ -
Page 5: Remote Control Specifications
REMOTE CONTROL SPECIFICATIONS Rated Voltage 3.0V (Dry Batteries R03/LR03×2) Signal Receiving Range 26 Ft. (8 Metres) Remote Operating Temperature 23°F-140°F (-5°C-60°C) Quick Start Guide AUTO COOL HEAT PLACE BATTERIES SELECT MODE SELECT TEMPERATURE AUTO HIGH PRESS POWER BUTTON POINT REMOTE TOWARD UNIT SELECT FAN SPEED ATTENTION Refer to Operating Instructions section of this manual for a detailed description of each setting. -
Page 6: Handling The Remote Control
HANDLING THE REMOTE CONTROL Inserting and Replacing Batteries Note • 2 AAA batteries are included. • Remove batteries from packaging and place batteries into the remote. To insert batteries, slide down back cover of the remote control to expose the battery compartment. Insert batteries accordingly matching the (-) and (+) terminals of the battery. - Page 7 HANDLING THE REMOTE CONTROL Battery Disposal Do not dispose of batteries as unsorted municipal waste. Refer to local laws for proper disposal of batteries. Tips • The remote control must be within 26 ft (8m) of the unit. • The unit will beep when remote signal is received. •...
-
Page 8: Remote Functions
REMOTE FUNCTIONS Before you begin using your new air conditioner, make sure to familiarize yourself with its remote control. The following is a brief introduction to the remote control itself. For instructions on how to operate your air conditioner, refer to the Operating Functions section of this manual. TEMP TEMP Decreases temperature in 1°F (1°C) increments. -
Page 9: Remote Display Icons
REMOTE DISPLAY ICONS The following icons will appear upon powering the remote. AUTO COOL HIGH HEAT Mode Display AUTO COOL HEAT Displayed when signal is being transmitted Displayed when unit is turned ON Displayed when TIMER ON time is set Displayed when TIMER OFF time is set Will show set temperature, room temperature and TIMER ON/OFF desired time Displayed when the remote is locked... -
Page 10: Operating Instructions
OPERATING INSTRUCTIONS ATTENTION Before powering on, assure the unit is plugged in the correct outlet configuration. COOL Mode Press the MODE button to select COOL mode. Set your desired temperature using the TEMP or TEMP button. Press FAN button to select the fan speed: AUTO, LOW, MED or HIGH. - Page 11 OPERATING INSTRUCTIONS FAN Mode Press the MODE button to select FAN mode. Press FAN button to select the fan speed: AUTO, LOW, MED or HIGH. Press the ON/OFF button to start the unit. Note • When in FAN mode the set temperature cannot be changed.
- Page 12 OPERATING INSTRUCTIONS TIMER ON Setting Press TIMER ON button to initiate the Use the TEMP UP and DOWN button With the remote pointed at the unit, ON time sequence. to set desired time. wait for 1 second until a beep is heard. This indicates the setting has been set.
- Page 13 OPERATING INSTRUCTIONS TIMER ON & OFF Setting (Example) The Timer function can be programmed for both ON and OFF in current time as shown in the example below. xn xn TIMER ON TIMER OFF Ex. If current time is 1:00 PM and the TIMER ON is set to 2.5Hr, and TIMER OFF at 5.0Hrs, the unit will turn on at 3:30 PM and off at 6:00 PM.
- Page 15 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details.
