Grasshopper 721D2 Operator's Manual & Parts List page 5

OPTIONAL HYDRAULIC LIFT ASSEMBLY
Item Item Item Item Item Order Order Order Order Order Description Description Description Description Description
N o . N o . N o . N o . N o . N o .
N o . N o . N o . N o .
1 100860 Oil Filter
2 101022 Filter Base Assembly
(includes items 3 – 5)
3 101027 Filter Base
4 360076 Adapter w/O-Ring
5 360077 Adapter w/O-Ring
6 101692 Aluminum Tank Assembly
7 240151 Hook Bolt
8 253035 Whiz Nut
9 253043 Whiz Nut
10 253066 Whiz Nut
11 253173 Whiz Bolt
12 253192 Whiz Bolt
13 253203 Whiz Bolt
14 257062 Washer
15 257106 Washer
16 260648 Cotter Pin
17 261339 Clevis Pin - Sq. Shank
18 263500 Retainer – External
19 280264 Hose Clamp Spring TOC
20 280266 Hose Clamp Spring TOC
21 280268 Hose Clamp Spring
22 281540 Square Key
23 281580 Square Key
24 290021 Cylinder – Hydraulic
290096 Cylinder Seal Kit
25 290074 Pump – Hydraulic CCW w/Solenoid
144950 Solenoid Valve
26 323951 Counter weight
27 360005 Adapter Tee
28 360012 Adapter Fitting
29 360040 Adapter O-Ring
30 360045 Adapter O-Ring
31 360050 Adapter O-Ring
32 360052 Adapter O-Ring
Item Item Item Item Item Order Order Order Order Order Description Description Description Description Description
N o . N o . N o . N o . N o . N o .
N o . N o . N o . N o .
33 360055 Adapter O-Ring 90°
34 360260 Brass Hose Insert
35 363832 Fitting
36 363857 Fitting 90°
37 366115 Reducer Tee
38 388560 Coupler Sleeve Nylon
39 388576 Coupler Hub
259302 Set Screw - Nylon
40 424150 Stabilizer - Coupling
41 424302 Hose Assembly
42 424310 Hose Assembly
43 424349 Hose Assembly
44 821804 Hydraulic Hose
45 604779 Steering Lever Assembly w/Switch
(includes items 46 – 48)
46 422095 Vinyl Cap
47 422179 Handle Grip
48 604799 Switch/Mount Assembly
49 643915 Mount - Weight
50 725326 Pump Mount Plate
51 729691 Weight Cover
52 732614 Oil Filter Base
53 755128 Mount – Aluminum Oil Tank
54 770045 Washer
55 774020 Washer
56 780507 Flow Restrictor
57 821781 Hose – Hydraulic
58 821802 Hose – Hydraulic
59 831039 Flex Coupler
60 887119 Pin – Cylinder Mount
61 360081 Adapter Fitting
62 821806 Hose – Hydraulic
63 257412 Lock Washer
64 243331 Bolt
65 165400 Decal- Oil Specification
02-05043
52
Rev. 03-07
SPECIFICATIONS
Engine Kubota three cylinder
4 cycle liquid cooled
Model No. D722
Horsepower (G.I.H.P.) 15.6 kw
Displacement 719 cc
No-load rpm 3250
Charging System 12VDC 12.5 amp.
negative ground
Starter Electric
Electrical System Safety interlocked
PTO 3000 r.p.m. (max.)
Electric clutch
Transmission Dual path
hydrostatic direct drive
Steering Dual levers independently
control speed and direction
of travel.
Zero turning radius (center of
machine is pivot point).
Speed
Forward (variable) 0 to 13.7 km/h
Reverse (variable) 0 to 8.0 km/h
Fuel Tank Capacity 16.3 l.
Tire Sizes
Front Drive Wheels
Standard 22 x 11 x 10 - 4 ply rated
Optional 22 x 10 x 10 - 4 ply rated
Tail Wheel 13 x 6.50 x 6 rib - 4 ply rated
Dimensions of Tractor
Seat Back Height 1.17 m
Seat Cushion Height .78 m
Tractor Width 1.26 m
Tractor Length 1.98 m
Wheel Base 1.26 m
Weight - Uncrated 416.8 kg
Weight - Crated 467.0 kg
Hour Meter Standard
721D 2
5
