Summary of Contents for Butler ECO-920S
- Page 1 USER MANUAL Electric Convection Oven with Steam: ECO-920S...
- Page 2 User Manual Thanks for your using of our company product, in order to ensure the product performance, give full play to the role, please have a read of this manual to avoid unnecessary loss and damage, and get a further study of our product characteristic、 installation and operation.
- Page 3 User Manual Index Safety instruction Control board operation instruction III. Functions Machine illustration diagram Installation instruction Operation instruction VII. Warning VIII. Maintenance Trouble shooting Specification Wiring diagrams...
- Page 4 User Manual 1. Safety instruction Warning: 1. Please confirm the power supply is suitable for the machine using. Also please confirm if the power socket match the power wire parameter. 2. Please use the oven within the limits of the temperature according to the data plate.
- Page 5 User Manual ，then the program 1. Turn on the power, choose a program number, such as○ display board would display "nX" which means the machine go into manual mode. Press "Set Up" switch and you can adjust the temperature and time, then press "Set Up"...
- Page 6 6. Heat dissipation function, can cool down the machine quickly. 4. Machine illustration diagram MODEL A（MM） B（MM） C（MM） D（MM） E（MM） ECO-920S 5. Installation instruction 1. All the electrical power unit and circuit connection must be installed by qualified electrician with safety standard.
- Page 7 User Manual 7. Connect the cable to the power supply fixed by using a screwdriver according to the connection diagram, then loosen the screw inside the power point and plug the cable in, make sure the sheet copper compress the power line tightly. If the connection is incorrect, it may cause joint heating and burning off the power cord.
- Page 8 User Manual 7. Warning 1. If you want to clean、repair or move the machine, please pull out the plug first. 2. Please don’t touch the switch or plug with wet hand. 3. The machine can’t be flushed directly, and please be careful don’t let any water flow into the switch when cleaning.
- Page 9 User Manual 10. Specification Temperature Internal Voltage Power Model Dimension(mm) range dimension (mm) (KW) ECO-920S 0~350 ℃ 920X825X595 620X450X420 380V/50Hz 11. Wiring diagrams...
- Page 10 User Manual Marketed by: TRUFROST COOLING PRIVATE LIMITED 1215, 12th Floor, Tower B, Emaar Digital Greens, Golf Course Extn. Road, Sector 61, Gurugram – 122102 T. +91-124- 4246560 info@trufrost.com www.trufrost.com...
