Summary of Contents for ODM VIS 300
- Page 1 ODM VIS300 Specs Provided by www.AAATesters.com User’s Guide VIS 300 - Video Inspection Scope _____________________________________________________________________________ VIS1-00-2000, Rev A, 6-09-10 Specifications subject to change without notice...
-
Page 2: Table Of Contents
A. Connecting probe to VIS display B. Installing appropriate adapter tips C. VIS 300 focus system D. VCM 410 Operation E. VIS 300 – VC Operation Section 3 – General Care and Maintenance A. General overview B. Probe optical lens care & cleaning C. -
Page 3: Section 1 - General Overview
A. VIS 300 Probe B. VIS 300 Display C. Video Capture VIS 300 – VC & VCM 410 Section 1 - General Overview A. The purpose of this user’s guide is to familiarize the user with the features and benefits of the VIS 300s. -
Page 4: Unpacking And Inspection
Section 2 - Operating Instructions and Feature Overview The VIS 300 is an extremely easy to use video fiber connector inspection system. The VIS 300 advances field connector inspection by a unique focus system that virtually eliminates the need for the user to place his or her hand in the same position each time for effective focus control. - Page 5 The VIS 300 comes with two user-selected adapter tips. Optional tips for most commonly used connectors are available. The VIS 300 monitor is supplied in a padded nylon case. Both the probe and monitor are transported in a hard carry case that also includes the charger, extra adapter tips and cleaning aids.
- Page 6 2. Focus Ring – Two focus methods are used to adjust the image while using the VIS 300. The first technique is used when using any of the “universal” tips for direct connector inspection. To focus, insert the connector into the adapter tip and adjust the image by turning the Focus Ring with the users thumb.
- Page 7 8. See #7 above 9. AC Charger input – If the VIS 300 display does not illuminate the screen once it is powered on, then the battery must be charged. To charge the battery and simultaneously use the VIS 300,...
- Page 8 Total charge time is approximately three hours and indicates a fully charged battery by displaying a green LED on the charger. While charging this LED remains red. 10. Power On – The VIS display will indicate power available to the LCD and Probe by indication of the green LED.
-
Page 10: Section 3 - General Care And Maintenance
For more recommendations on this subject please call ODM Inc. @ 603-524-8350. C. Display maintenance – The VIS 300 is housed in a padded protective nylon case. Although this case provides field abuse protection, the VIS 300 display must be protected from direct impact. Should... - Page 11 D. VIS 300 battery maintenance – The VIS 300 includes a rechargeable Lithium Ion battery capable of powering the unit for more than 8 hours of continuous use. The VIS 300 includes a “smart charging adapter” that charges the VIS 300 and shuts down the charging when fully charged. Approximately three hours are necessary for full charge.
- Page 12 1.2lb ( .54kg) (monitor, probe & case) Operating Temp. 0º to 50 º C Storage Temp. - 40 º to 70 º C Thank you for choosing Optical Design Manufacturing Inc. 143 Lake St. Laconia, NH 03246, USA 603-524-8350 www.odm-inc.com tech.support@odm-inc.com...
