Summary of Contents for Redwood RWC2020A
- Page 1 RWC2020A Interference Generator Operating Manual Version 1.00 (ENG) (RWC2020A FW Version 1.00) June 2019...
-
Page 2: Table Of Contents
Contents I. General Information ..............................2 1.1 Warranty ................................3 1.2 Safety Considerations ............................4 1.2.1 Injury Precautions ............................ 4 1.2.2 Product Damage Precautions ........................4 1.2.3 Safety Symbols and Terms........................5 1.3 Contact Information ............................6 1.4 Key Features ............................... 7 1.5 Specifications.............................. -
Page 3: General Information
I. General Information This chapter covers specifications, key features, warranty, and safety consideration of the Instrument. Warranty Safety Considerations Contact Information Key Features Specifications Initial Inspection Power Requirement Operating Environment... -
Page 4: Warranty
1.1 Warranty RedwoodComm Warrants that this product will be free from defects in materials and workmanship for a period of two(2) years from the date of shipment. During the warranty period, RedwoodComm will, at its option, either repair or replace products that prove to be defective. For warranty service or repair, Customer must notify RedwoodComm of the defect before the expiration of the warranty period and make suitable arrangements for the performance of service. -
Page 5: Safety Considerations
1.2 Safety Considerations Review the following safety precautions to avoid injury and prevent damage to this product or any product connected to it. 1.2.1 Injury Precautions Use Proper Power Cord To avoid fire hazard, use only the power cord specified for this product. Avoid Electric Overload To avoid electric shock or fire hazard, do not apply a voltage to a terminal that is specified beyond the range. -
Page 6: Safety Symbols And Terms
Do not operate this product from a power source that applies more than the voltage specified. Main supply voltage fluctuations do not to exceed ± 10% of the nominal voltage. Provided Proper Ventilation To prevent product overheating, provide proper ventilation. Do Not Operate With Suspected Failures If you there is damage to this product, have it inspected by qualified service personnel. -
Page 7: Contact Information
1.3 Contact Information The contact information of RedwoodComm is as follows: Headquarters in Korea: +82-70-7727-7011 Branch office in Canada: +1-604-720-2688 Technical Support: support@redwoodcomm.com Homepage: http://www.redwoodcomm.com... -
Page 8: Key Features
1.4 Key Features General Descriptions RWC2020A is an interference generator being capable to be used for the purpose of a wide range of tests or measurements, e.g. the Listen Before Talk (LBT) test, the Gateway Non- regression tests, the Intermodulation Immunity test and so on. RWC2020A shall be connected to RWC5020A via RS-232C for a remote control and setup of the full automation tests. - Page 9 PC Software Control of RWC2020A is only provided via RWC5020A PC Application Software. Please refer to RWC5020A PC Application Software to see how the tests are performed using RWC2020A.
-
Page 10: Specifications
1.5 Specifications Frequency Range : 400MHz ~ 1000MHz Resolution : 100Hz Accuracy : ±2ppm/year @ operating temperature Output Level Range: -10dBm ~ -100dBm Resolution : 0.1dB Accuracy : ±1dB RF Characteristics Phase Noise (Single-tone mode) : -103dBc@1kHz / -110dBc@10kHz / -110dBc@100kHz / -138dBc@1MHz ... -
Page 11: Initial Inspection
Item Code Item Specifications Q’ty C2020A-00 RWC2020A Interference Generator 2020A00-8001 Manual 6016-0001-001 MF405, SMA(M) to SMA(M) Cable L:0.5m 6211-0002-001 SMA(F) to N(M) Adaptor... -
Page 12: Smps Adaptor
1.7 SMPS Adaptor Items Specifications Input AC 100-240V, 50/60Hz, 1.0A Output DC 12V, 3A CAUTION: If AC power is beyond the range of operation, the adaptor may malfunction or could be permanently damaged. Main supply voltage fluctuations should be not to exceed ±10% of the nominal voltage. -
Page 13: Operating Environment
1.8 Operating Environment Refrain from using this equipment in a place subject to much vibration, direct sunlight, outdoor and where the flat is not level. Also, do not use it where the ambient temperature is outside 5 °C to 40 °C, and altitude is more than 2000m. -
Page 14: Operation
II. Operation This section describes the basic concepts and details of operating RWC2020A Interference Generator. Understanding the basic concept of your RWC2020A may help you use it effectively. 2.1 Front Panel View 2.2 Rear Panel View 2.3 Main Screen 2.4 Information Screen 2.5 Ethernet IP Setup... -
Page 15: Front Panel View
2.1 Front Panel View Fig 2.1 RWC2020A Front Panel View Items Names and Descriptions 2.81 inch OLED Display Power Switch RF OUT Connector... -
Page 16: Rear Panel View
2.2 Rear Panel View Fig 2.2 RWC2020A Rear Panel View Items Names and Descriptions RS-232C Interface Ethernet Interface Function Key SD Card Slot DC 12V/3A Power Input... -
Page 17: Main Screen
2.3 Main Screen 2.3.1 Mode Switch RWC2020A Interference Generator has four operating modes: LBT channel mode, LBT burst mode, single-tone mode, and dual-tone mode. It can be switched from one to another by changing OP_MODE in parameter setup of RWC5020A, which shall be connected with an RS-232C cable. An example screen of RWC5020A for controlling RWC2020A is shown in Fig 2.3. - Page 18 This parameter controls the status of RF TX output. PATH_LOSS The path loss can be measured between the RF port of RWC2020A and the RF port of DUT via an RF splitter. RWC2020A’s real output power will be increased by this value to compensate the path loss.
-
Page 19: Lbt Burst Mode
CH_POW_01 ~ 07 These parameters define the offset values for RF channels with respect to the reference power level. 2.3.3 LBT Burst Mode In LBT burst mode, two different power levels can be applied to all RF channels with different time intervals. -
Page 20: Single-Tone Mode
This parameter controls the status of RF TX output. PATH_LOSS The path loss can be measured between the RF port of RWC2020A and the RF port of DUT via an RF splitter. RWC2020A’s real output power will be increased by this value to compensate the path loss NORMAL_POWER This parameter defines the power level of normal state which will be applied to all channels. -
Page 21: Dual-Tone Mode
This parameter controls the status of RF TX output. PATH_LOSS The path loss can be measured between the RF port of RWC2020A and the RF port of DUT via an RF splitter. RWC2020A’s real output power will be increased by this value to compensate the path loss. - Page 22 This parameter controls the status of RF TX output. PATH_LOSS The path loss can be measured between the RF port of RWC2020A and the RF port of DUT via an RF splitter. RWC2020A’s real output power will be increased by this value to compensate the path loss.
- Page 23 This parameter defines the frequency offset of the second signal relative to the FREQ1. FREQ2 This parameter indicates the frequency of the second signal (display only).
-
Page 24: Information Screen
2.4 Information Screen RWC2020A provides an additional information screen for users’ conveniences, which will be displayed by pressing the FN key on the rear panel. It shows its serial number, the IP address, and the firmware version. Moreover, the IP address is configurable remotely by RWC5020A. -
Page 25: Ethernet Ip Setup
2.5 Ethernet IP Setup Upgrading of RWC2020A firmware is only available through Ethernet interface, so IP configuration must be done before upgrading. IP configuration of RWC2020A is shown in RF parameter screen of RWC5020A as “IP_TYPE” and “IP_ADDR”. “IP_TYPE” parameter can be set to DYNAMIC or STATIC; DYNAMIC means that IP address may be obtained from the DHCP server automatically, and this configuration is recommended for RJ45 connection to a network hub. -
Page 26: Firmware Upgrade
2.6 Firmware Upgrade As RWC2020A adapted Flash Memory, it is available to upgrade easily by using a remote PC without changing the hardware. For upgrading, ‘RWC_Upgrader’ program shall be used, which is provided together when the product is purchased or available to download the upgrade package including itself and the upgrade binary files from RedwoodComm website (http://www.redwoodcomm.com). - Page 27 1) If Normal Firmware Upgrade Procedure fails during upgrading, the internal memory may be damaged. In this case, RWC2020A may not boot correctly. Then RWC2020A must be upgraded in Emergency Upgrade Mode. 2) Turn off RWC2020A. While keeping FN key on the rear panel pressed, turn on RWC2020A. Then...
- Page 28 RWC2020A will boot in Emergency Upgrade Mode as the following figure. 3) Make direct connection between a remote PC and RWC5020A using a crossover cable and wait until IP address of RWC2020A will be displayed on the screen. 4) Follow the steps 3) to 6) of Normal Firmware Upgrade Procedure.
-
Page 29: Remote Control Interface
RWC2020A can be controlled by RWC5020A through an RS-232C interface, so that all the necessary remote commands of RWC2020A are provided as ones of RWC5020A. Please refer to the user manual of RWC5020A to learn how to control RWC2020A remotely. -
Page 30: Revision History
III. Revision History Version Date Description V1.0 June 6 2019 Firmware version: V1.00 - First released...
