Brother HL-3260N Quick Setup Manual

Laser Printer HL-3260N
Quick Setup Guide
Read the "Safety Sheet" first to ensure that you use this printer safely.
Read this "Quick Setup Guide" before you set up the printer.
Before you can use the printer, you must set up the hardware and install the driver.
Identify the operating system on your computer (Windows
® ®
Windows 2000 or Macintosh ).
The interface cable is not a standard accessory. Please purchase the appropriate interface
cable for the interface you intend to use (parallel or Network). Most existing parallel cables
support bi-directional communication, but some might have an incompatible pin assignment
or may not be IEEE 1284 compliant.
Follow the instructions in this guide for your operating system and interface.

Carton components

Carton components may differ from one country to another.
Save all packing materials and the printer carton. They should be used when shipping the printer.
CD-ROM Tray number seal AC power cord Toner
(in Paper tray 2)
Documents
Step 2 Install the Toner Bottle
green
handle
1 Lift the green handle. 2 While pushing the green lever down (1), hold
the handle and slide the toner holder out
slightly (2).
Step 3 Load paper into the paper tray
Slide the paper tray out. Make sure the side guide lock lever
1 2
is set to the "unlocked" position.
Step 4 Print test page
paper sensor
I
ON
O
OFF
1 Set the paper sensor. 2 Make sure that the printer power switch is off.
Connect the AC power cord to the printer.
Do not connect the interface cable.
Set up the printer

Step 1 Unpack the Printer

® 95 / 98 / Me, Windows NT ® 4.0,
Remove the tapes.
1
paper tray 1
Printer
Drum
(pre-installed)
Slide paper tray 1 out.
6
LJ2343001 Printed in Japan
toner holder
green lever
3 Release the green lever and slide the
toner holder out gently until it stops.
Up to here
While pressing the release lever of Align the right side of the paper stack
3 4
the side guide (1), slide the side and load it into the paper tray.
guide wide open (2).
3 Plug the AC power cord into an AC outlet.
Turn the power switch on.
release lever
paper tray 2
Slide paper tray 2 out. Release the side guide lock lever (1) and then
2 3
slide the side guide while pressing the release
lever (2).
Repeat Steps 3 and 4 above on
7
paper tray 1.
toner bottle
lid
4 Rock the toner bottle gently several Put the toner bottle in the toner holder (1),
5
times (1), and remove the black lid (2). then push the top of the bottle downwards to
lock it in place (2).
While pressing the release lever of Set the side guide lock to the
5 6
the side guide (1), align the side "locked" position.
guide for the loaded paper size (2).
READY
I ON
O
OFF
4 After the printer has finished warming up, the
READY message appears.
side guide
lock lever
side guide
Remove the tape and the
4
cardboard.
front cover
Slide paper tray 1 and 2 into the printer Open the front cover.
8 9
until they stop.
6 Slide the toner holder into the printer until
it clicks into place and then push the
green handle down.
rear guide
release lever
While pushing the release lever of
7
the rear guide (1), align the rear
guide for the loaded paper size (2).
PRINTING
5 Press the Go switch. The printer prints a test page.
Check that the test page has printed correctly.
toner bottle
Take the toner bottle out of paper
5
tray 2.
red tag
Remove the red tag, the metal
10
fitting and the two tags.
Close the front cover.
7
paper size dial
Adjust the paper size dial to match the
8
loaded paper size (1).
Slide the paper tray into the printer (2).
Note: When you want to set the
Control Panel message language,
refer to the Control Panel section on
the reverse side of this sheet.
Continue to the reverse side.
