HRW EKey EKRXGSM Quick Start Manual

EKRXGSM – Remote Receiver c/w GSM Module
The EKRXGSM remote control receiver is designed to deliver unparalleled flexibility for all domestic and
commercial applications.
Combining a normal E-Key receiver with a powerful GSM module enables any gate/door or alarm panel to be
triggered by both E-Key s and mobile or fixed telephones. The receiver can be triggered by simply calling the
GSM module. As soon as the EKRXGSM detects an incoming call from a valid telephone it will trigger it's
output as if a valid E-Key were used - without answering the call.
All features including phone number restriction, E-Key addition or deletion etc can be remotely changed via
password protected SMS from any mobile phone or by a PC using simple software combined with a GSM
modem.
Applications
Garage doors, automatic gates
Remote arming and disarming of security alarms
Remote area control
Personal emergency or duress alarms
Features
Can be used to replace any existing remote control system
Free activation of gate/door by ringing the EKRXGSM phone number
Add and delete E-Keys via SMS
Access can be restricted to a group of valid phone numbers
All settings are be password protected
Simple system management by sending SMS using a mobile phone or PC and GSM modem
combination
Optional 5 second call-back on activation to confirm reception of incoming call
Configurable external alarm input allows the EKRXGSM to send alarm SMS messages to selected
users upon activation
•
No price penalty for far superior technology
