Ecomax
Customer Product Manual
Part 7593428_01
Issued 07/2019
For parts and technical support, call the Industrial Coating
Systems Customer Support Center at (800) 433-9319 or
contact your local Nordson representative.
This document is subject to change without notice.
Check http://emanuals.nordson.com for the latest version.
NORDSON DEUTSCHLAND GMBH
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Nordson EcoMax 1
- Page 1 Issued 07/2019 For parts and technical support, call the Industrial Coating Systems Customer Support Center at (800) 433-9319 or contact your local Nordson representative. This document is subject to change without notice. Check http://emanuals.nordson.com for the latest version. NORDSON DEUTSCHLAND GMBH...
- Page 2 Contact Us Notice This is a Nordson Corporation publication which is protected by copyright. Nordson Corporation welcomes requests for information, comments, and Original copyright date XXXX. No part of this document may be inquiries about its products. General information about Nordson can be...
- Page 3 Change Record Change Record Revision Date Change 7593428_01 Part E 2019 Nordson Corporation...
-
Page 5: Table Of Contents
..........Electrical and Pneumatic Diagrams ..... . . E 2019 Nordson Corporation 7593428_01 Part... -
Page 6: Safety
Freestanding ductless powder coating booth. Can be used for multi−colour or dedicated single colour. Use of Nordson equipment in ways other than those described in the documentation supplied with the equipment may result in injury to persons or damage to property. -
Page 7: Personal Safety
Clean, maintain, test, and repair equipment according to the instructions in your equipment documentation. Use only replacement parts that are designed for use with original equipment. Contact your Nordson representative for parts information and advice. E 2019 Nordson Corporation 7593428_01... -
Page 8: Grounding
Disconnect and lock out electrical power. Close pneumatic shutoff valves and relieve pressures. Identify the reason for the malfunction and correct it before restarting the equipment. Disposal Dispose of equipment and materials used in operation and servicing according to local codes. 7593428_01 Part E 2019 Nordson Corporation... -
Page 9: Description
EcoMax Description The Nordson EcoMax booth is a compact powder coating booth and recovery system with primary and secondary filters. It is available in 6 different variations (1 − 6). See the Specifications section. Each has a self−contained cartridge filter extract system coupled to the booth, with the option to pulse clean the cartridge filters to prolong life. -
Page 10: Installation
5. Set all regulators to zero, ensure that the service air line has been drained before opening the valve to the control panel. Check for air leaks, remedy as necessary. 6. Set the pulse air pressure to 4.5 bar. 7. Check operation of the booth light. 7593428_01 Part E 2019 Nordson Corporation... -
Page 11: Electrical
The pneumatic connection (BSP thread) is made next to the air reservoir or into the Nordson control panel and is provided with a ball valve for system isolation. Ensure that when bringing in the air connection there is a drain leg for the collection of any materials or oil that may be in the air lines before the connection is made to the control panel. -
Page 12: Operation
Using a scoop, empty the waste powder into the desired container. Control Panel Identification Figure 2 10. Pressure regulator with gauge 13. Emergency Stop 11. Light switch 14. Mains isolator 12. Fan START/STOP 15. RESET button 7593428_01 Part E 2019 Nordson Corporation... -
Page 13: Control Screen
When the system is turned on, the controller always starts in the operating mode. You can adjust the time delay (PAUSE TIME) between filter cleaning pulses and the duration (PULSE TIME) of the pulse. E 2019 Nordson Corporation 7593428_01 Part... -
Page 14: Control Screen − Parameter Setting
Use the LEFT (1) button to go back from this screen. Parameter Factory Setting Minimum Value Maximum Value Pause time Pulse time NOTE: To exit the settings screen, push buttons LEFT (1) and RIGHT (4) at the same time. 7593428_01 Part E 2019 Nordson Corporation... -
Page 15: Maintenance
Check the detector lenses and clean if necessary. Ensure the built−in airwash (if fitted) system is supplying sufficient air to the detector lens. Do NOT blow high pressure air onto the lenses, this can damage them or block the airwash system. E 2019 Nordson Corporation 7593428_01 Part... -
Page 16: Monthly Maintenance
Annual Maintenance Equipment Procedure Fan Assembly If the fan changes in vibration or noise levels, contact your Nordson representative. Refer to the manufacturers instructions for lubrication and maintenance of the fan motor. Fan Enclosure Inspect for powder or foreign particles. Vacuum the enclosure clean and if ex- cessive powder or foreign particles are found, contact your Nordson representative. -
Page 17: Troubleshooting
Follow the safety instructions in this document and all other related documentation. These troubleshooting procedures cover only the most common problems. If you cannot solve a problem with the information given here, contact your local Nordson representative for help. Problem Possible Cause... -
Page 18: Parts
EcoMax Parts To order parts, call the Nordson Industrial Coating Systems Customer Support Center at (800) 433-9319 or contact your local Nordson representative. See Figure 7 − Page 14 Item Part Description Quantity Note 7034133 FILTER MEDIA,GEN5_AF,592 X 592 768405... - Page 19 EcoMax Parts Identification Figure 7 E 2019 Nordson Corporation 7593428_01 Part...
-
Page 20: Operating Environment
2°C or less dewpoint − oil free − filtered to 5µ or less Air quality 80dB Maximum during normal operation Noise No more than 18.3 m/min (60FPM) Cross drafts NOTE: Temperature of parts entering the booth should not be more than 49°C (120°F) 7593428_01 Part E 2019 Nordson Corporation... -
Page 21: Specifications
EcoMax Specifications NOTE: Nordson reserve the right to change specifications/dimensions at any time Ecomax 1 − Part Number 7035226 1500 EcoMax 1 − Dimensions Figure 8 Description Data Airflow 1300 m Number of cartridges Electrical power consumption TBC Kw Supply voltage... -
Page 22: Ecomax 2
Ecomax 2 − Part Number 7035227 1116 1050 1910 1200 EcoMax 2 − Dimensions Figure 9 Description Data Airflow 2600 m Number of cartridges Electrical power consumption 2.2 Kw Supply voltage 400v / 50Hz Weight TBC kg 7593428_01 Part E 2019 Nordson Corporation... -
Page 23: Ecomax 3
Ecomax 3 − Part Number 7035228 2260 1400 1880 EcoMax 3 − Dimensions Figure 10 Description Data Airflow 5600 m Number of cartridges Electrical power consumption 5 Kw Supply voltage 400v / 50Hz Weight 950 kg E 2019 Nordson Corporation 7593428_01 Part... -
Page 24: Ecomax 4
EcoMax 4 − Part Number 7035229 1796 1050 1910 1880 EcoMax 4 − Dimensions Figure 11 Description Data Airflow 5600 m Number of cartridges Electrical power consumption 5 Kw Supply voltage 400v / 50Hz Weight 900 kg 7593428_01 Part E 2019 Nordson Corporation... -
Page 25: Ecomax 5
EcoMax 5 − Part Number 7035230 2300 1050 1910 EcoMax 5 − Dimensions Figure 12 Description Data Airflow 5600 m Number of cartridges Electrical power consumption 5 Kw Supply voltage 400v / 50Hz Weight 850 kg E 2019 Nordson Corporation 7593428_01 Part... -
Page 26: Ecomax 6
EcoMax 6 − Part Number 7035231 EcoMax 6 − Dimensions Figure 13 Description Data Airflow 11200 m Number of cartridges 2 * 4 Electrical power consumption 2 * 5Kw Supply voltage 400v / 50Hz Weight TBC kg 7593428_01 Part E 2019 Nordson Corporation... -
Page 27: Electrical And Pneumatic Diagrams
Ecomax Control Panel ###### NOTE: As there are several versions of the Ecomax booth, there are also several versions of the Control Panel drawings. Please contact your Nordson representative to obtain the relevant drawings. E 2019 Nordson Corporation 7593428_01 Part...
