18Gbps HDMI In-line Signal Re-Clocker with EDID Management
CON-H2-EDID
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the
installation process.
IMPORTANT! Installation Requirements
• Advanced configuration of this product requires the use of the use of the
WyreStorm Management Suite
the latest version from the product page before continuing with the
installation.
• Visit the product page to download the latest firmware, document version,
additional documentation, and configuration tools.
• Read through the
Wiring and Connections
guidelines before creating or choosing premade cables.
• While this product supports CEC for the HDMI outputs, WyreStorm cannot
guarantee compatibility with all forms of CEC communication.
Basic Wiring Diagram
CON-H2-EDID
Front
Copyright © 2019 WyreStorm Technologies |
CON-H2-EDID Quickstart Guide | 190530
v1.6 or higher configuration tool. Download
section for important wiring
HDR Source
AC
Mains
Audio Video
Receiver
wyrestorm.com
In the Box
1x CON-H2-EDID
1x DC 12V 1A Power Supply (US/UK/EU/AU)
3x 3-Pin Terminal Block
2x Mounting Brackets
1x Quick Start Guide (This Document)
Amplifier
Analog Audio
Projector Screen
1 of 4
Quickstart Guide
CON-H2-EDID
Rear
Short Throw
KEY
Projector
Passive HDMI
Digital Audio
Analog Audio
Control
Power
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
support@wyrestorm.com
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Wyrestorm CON-H2-EDID
- Page 1 18Gbps HDMI In-line Signal Re-Clocker with EDID Management Quickstart Guide CON-H2-EDID WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation process. In the Box IMPORTANT! Installation Requirements 1x CON-H2-EDID •...
- Page 2 Wiring and Connections WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in its entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
- Page 3 RS-232 Guidelines for pinout. 2. Open the WyreStorm Management Suite and select the CON-H2-xxxx Configuration Tool from the menu. 3. Under RS-232 Port Configuration select the COM port for the PC and set the baud rate to 57600. 4. Select the Connect button to connect the PC to the converter.
- Page 4 Safety and Emission CE | FCC | RoHS | RCM Note: WyreStorm reserves the right to change product specification, appearance or dimensions of this product at any time without prior notice. Warranty Information WyreStorm Technologies LLC warrants that its products to be free from defects in material and workmanship under normal use for a period of five (5) years from the date of purchase.
