Temperature Sensor Replacement
Kit Part Number
PTRKIT122
PTRKIT122
PARKIT01
Each Kit Includes:
• Temperature Sensor
WARNING
!
Indicates a potentially hazardous situation which,
if ignored, can result in serious injury or substan-
tial property damage.
WARNING
!
For your safety, turn off electrical power supply
at service panel and allow unit to cool before pro-
ceeding to avoid possible electrical shock and
scald hazard. Failure to do so can cause severe
personal injury or death.
NOTICE
The red wire adapter shipped with the temperature
sensor is not required with the HeatMaster.
2019-48 Instinct Temperature Sensor Replacement
Revised 1/8/2020
Description
Supply Temperature Sensor Replacement
Return Temperature Sensor Replacement
Flue Temperature Sensor Replacement
Recommended Tools:
NOTICE
All Instincts
All Instincts
All Instincts
• Adjustable Wrenches
• Phillips Head Screwdriver
Indicates special instructions on installation, operation
or maintenance, which are important to equipment
but not related to personal injury hazards.
WARNING
!
Failure to follow instructions below can result in
severe personal injury or damage if ignored.
•
Instructions are for a qualified installer/ ser-
vice technician only.
•
Read all instructions before proceeding.
•
Follow instructions in proper order.
Model
1
Advertisement
Table of Contents
Summary of Contents for TriangleTube PTRKIT122
- Page 1 Instinct Temperature Sensor Replacement Kit Part Number Description Model PTRKIT122 Supply Temperature Sensor Replacement All Instincts PTRKIT122 Return Temperature Sensor Replacement All Instincts PARKIT01 Flue Temperature Sensor Replacement All Instincts Each Kit Includes: Recommended Tools: • Temperature Sensor • Adjustable Wrenches •...
- Page 2 Instinct Temperature Sensor Replacement 1. Preliminary Instructions 1. Verify that the temperature sensor replacement kit is correct for the model of boiler. See table on page 2. Carefully open and unpack the PARTS BOX from its shipping carton. 3. Carefully remove and check for any damage. NOTICE Installing a damaged temperature sensor will cause mal- function of the boiler.
- Page 3 Instinct Temperature Sensor Replacement 3. Close all isolation valves on the system piping to 2. Thread the temperature sensor on by hand and the boiler. Close the fill valve line to the system. tighten as tightly as possible. Tighten the tempera- ture sensor an additional 1/4 turn using an adjust- 4.
