Summary of Contents for dedalo TRES TREMOLO

  • Page 2 Congratulations, you got the Tres! With its FET/LDR analog circuit which provides the most organic and warm tremolo, and its innovative μ-control technology, the Tres lets you create wave- forms and sounds that had never been possible. From the classic “vibrato” of old amplifiers, to rhythmic patterns and Fade/Kill effects.
  • Page 3 Controls Depth of the tremolo effect. At minimum, the “k” (KILL) mode is activated: 01 - DEPTH the modulation is made by the FET circuit and the sound gets chopped with sharp edges and more than 50dB of depth. Rotating the control to the right the Opto mode is activated, with its depth increasing from zero to the max as the control is turned.
  • Page 4 Controls Controls • f: FADE mode. In this mode the LFO stops and the output level is controlled by Turns on/off the effect. The true bypass switch allows your 10 - TRUE BYPASS the Control switch between full level (switch released) and silence (switch pressed). sound to remain intact when the effect is off.

  • Page 5: Problems And Solutions

    Use and care of the pedal Problems and solutions • To place a battery, remove the lid by removing screws. • The LED lights up but there is only sound when the effect is in bypass: • Use only regulated 9v dc adapter, with negative center polarity. In no way should be Make sure the instrument is properly connected to the INPUT jack, and the amplifier connected to 220V or adapters of other kinds.

  • Page 6: Terms Of Warranty

    • DEDALO will choose to repair or replace any faulty piece on the pedal at its sole option. • Failures due to accident or misuse are not covered in the warranty. • DEDALO is not responsible for any loss or damage the user may suffer as a result of Sound Settings using the pedal.
  • Page 7 Sound Settings Sound Settings Surf Trem Chopper Backwards Guitar Heartbeat Use control...

  • Page 8: Technical Specifications

    Order in the effects chain Technical specifications Model 2015 - TRS-5 True Bypass Input impedance: 700Kohm Power supply: DC 9v center negative (minimum 100mA) Battery Power: 9v Alkaline Power consumption: 40mA at 9v DC Dimensions: 12cm x 9.4cm x 5.4cm Weight: 475gr Trimpots: RV1: Level: output level of the effect.
