- Page 1 Hot water cleaner a p p a Operating instructions Tecno.Mec Casalgrande (RE) - I rev. MAG.2000...
-
Page 2: Table Of Contents
KAPPA cleaners are recommended for use in all fields of industry, agriculture, building industry and tourism. KAPPA can give you an answer to all your cleaning requirements both hobby and professional because it is light and handy, easy to use and easy to maintain. -
Page 3: Warranty Regulations
4) Periodical checks, calibrations, maintenance and modifications are not under warranty. DESCRIPTION OF THE MACHINE KAPPA is a cold and hot water high pressure cleaner formed by a metal chassis with wheels and a handle for moving; generator for the production of hot water; gas-oil burner; gas-oil tank;... -
Page 4: General View - Marking And Identification
GENERAL VIEW - MARKING AND IDENTIFICATION 1 - Automatic gun 2 - Lance handgrip 3 - Lance nozzle 4 - High pressure hose 5 - Water feeding hose (not supplied) 6 - Electric cable 7 - Rotating wheel with brake 8 - Detergent feeding connection 8b - Detergent regulation tap (only on prearranged models) 9 - Water feeding connection... -
Page 5: Operating Features
- High pressure hose - Washing lance with safety gun Optionals Tecno.Mec cleaners may be equipped with other accessories according to the cleaning needs; require them to your after sales service center. - SANDBLASTING KIT to sandblast with the high pressure power... -
Page 6: Improper Use
The rigorous observance of the instructions contained in this handbook is the main condition for a safe use of the cleaner. We will not be responsible for IMPROPER OR WRONG USE of our machines. For your information the following are examples of dangerous behaviour. IMPROPER USE Improper use is using the machine in manners for which it was not designed. -
Page 7: Packing And Transport
PACKING AND TRANSPORT The machine is fixed to a wooden pallet and covered by a corrugated board packaging which is fastened with a high resistance plastic ribbon. The machine packed in this way can be lifted also by a lift truck with forks. During shipment the container must be protected from atmospheric agents, such as rain, fog, sun, etc. - Page 8 INSTALLATION This operation must be done in clean and well-lit rooms. For references to the machine parts, see page 4 “General view” of this handbook 1 - Remove the packing carefully and inspect the machine for damage which may have occured during transport.
- Page 9 7) ATTENTION - Before doing the electric connections turn the main switch (FIG. 15) onto OFF position and be sure that the indications on the label (FIG. 18) correspond to those of the electrical mains. The installation must be carried out by qualified personnel in compliance with IEC 360 standards and current national and local regulations.
-
Page 10: Normal Use Of The Machine
NORMAL USE OF THE MACHINE Controls and indicators - Starting knob/burner temperature - On/Off general switch (according to the models the switch may be a I/O push button or a knob) - Pressure gauge AT THE BEGINNING OF EACH WORKING SHIFT - Verify that the supply cable, the plug and the water hose are in good condition. - Page 11 TO START THE MACHINE IT IS NECESSARY TO FOLLOW THE FOLLOWING SEQUENCE: 1) STARTING STAGES A) Turn on the water B) Set to zero the pressure by turning the regulating knob (see picture) on the lance (when present). The pressure is indicated by the pressure gauge (FIG.
- Page 12 3) SWITCHING OFF When finished using the machine act as follows: A) Close the spray gun B) Turn the knob (FIG. A) up to 0 (burner OFF) C) Open the spray gun and let water flow for about one minute (until the temperature lowers and cold water comes out).
- Page 13 - To protect against parts rebounding, it is necessary to wear protective clothes (especially during sandblasting or descaling operations, etc.) - Always wear rubber boots and protective glasses when using the machine - Never drink the water coming out from the machine, it has not to be used like drinkable water. - Never leave the machine unattended when it is running.
- Page 14 - Do not make repairs on, or do damage to the electrical cable - The machine must be used in rooms or in hours such to assure a sufficient lighting. - Do not direct the jet of water on the unit or any other electrical parts and appliances.
-
Page 15: Precaution In The High Pressure Hose Use
- Do not obstruct the exaust device - Avoid using the pump without water; it could damage the internal parts of the pump. PRECAUTIONS IN THE HIGH PRESSURE HOSE USE The high pressure hose supplied with the machine is subjected to rigorous safety controls. -
Page 16: Maintenance
MAINTENANCE WARNING If the machine is out of order or in the case of bad operation, immediately switch off the machine by means of the main switch, and advise the qualified personnel. Switch off the machine and disconnect the water and electrical mains and do not effect any repair. - Page 17 3) When the machine has been stored for a long time, there is a possibility of calcium deposits building up. This could make instant starting difficult. In this case to avoid the consequences of electrical over charging, before plugging the unit in, we suggest turning the motor shaft with a screwdriver (important: disconnect the machine before doing this operation).
- Page 18 9) In case the water filter is dirt or clogged, the water quantity is reduced and this could damage the pump. A lightly damaged filter do not carry on its work causing damages to the pump. Periodically (at least each 500 working hours) take the filter away and clean it to eliminate dirt.
-
Page 19: Troubleshooting
TROUBLESHOOTING In case of operating difficulties, please check the following table. If difficulties persist, contact a technician authorised by the manufacturer. WARNING: Before doing any kind of maintenance, disconnect the machine from the electric mains FAULT CAUSE REMEDY Pump running normally but pressure Pump sucking air Operate the pump with open lance does not achieve rated values... -
Page 20: Demolition Of The Machine
DEMOLITION OF THE MACHINE When you decide to discard the machine it is necessary to make it inactive: - empty the inner tanks - disconnect from the electrical mains - cut the external electric cable - cut the motor cable - take away the wheels ECOLOGICAL INFORMATIONS: It is necessary to follow the local laws concerning the connection to the water network. - Page 21 SINGLE-PHASE WIRING DIAGRAM...
- Page 22 THREE-PHASE WIRING DIAGRAM...
- Page 23 CONFORMITY DECLARATION THE MANUFACTURER Tecno.Mec Srl Via Canale, 114 - Loc. Villalunga 42013 CASALGRANDE (RE) - ITALY DECLARES THAT THE PRODUCTS: WATER CLEANERS KAPPA TO WHICH THIS DECLARATION REFERS, SATISFY THE FOLLOWING DIRECTIVES : 73/23/EEC - 89/392/EEC - 91/368/EEC - 93/44/EEC - 93/68/EEC Tecno.Mec Srl...
- Page 24 Via Canale, 114 - 42013 CASALGRANDE (RE) - ITALY Tel. +39-0522-840805 Fax +39-0522-849962 Internet: http://www.tecnomec.com...
