Polywood ADD200 Quick Start Manual

Model: ADD200
__(1) Chair frame
__(1) Back assembly
__(1) Hardware pack

TOOLS NEEDED

4MM HEX KEY, ALLEN, T-HANDLE
(INCLUDED)
4MM HEX KEY, ALLEN, SHORT ARM
(INCLUDED)
Qty. Description
A - .273 X 2.50 SOCKET WAFER A
4
B - .273 X 3 SOCKET WAFER A
2
ASSEMBLY INSTRUCTIONS
Step 1
Place back assembly in chair frame by
slipping bottom in first, then rotate back
into position as shown
Step 3
Attach arms to back assembly
using (2) .27x3" Screws
HARDWARE IS COATED STAINLESS STEEL UNLESS OTHERWISE SPECIFIED
Step 2
Attach back assembly to seat using
(2) .27x2-1/2" Screws
Atach back assembly to the
top of the back leg using
(2) .27x2-1/2" Screws
B
B
A
A
9/19/2014
A
A
