St. Michel London 750 Manual

Vanity Range
Basins
We suggest that you install your Wall hung vanity between 830-950mm high
to the nished top surface.
For internal division positions - please refer to cabinet speci cations
Note: Waste outlet positioned for standard chrome bottletrap and pop up
basin waste.
Illustrations are representations and not to scale
London 750
Product No: 1183, 1185
100
C L
to waste
outlet
372
London 1500DB
Product No: 1195, 1197
100
C L
to waste
outlet
297
Please note that these plumbing positions are for top mounted tapware. If you are
installing wall mounted tapware please check the tapware manufacturers instructions
for plumbing positions and installation guides.
Hot & Cold Water Inlet
St Michel pursues a policy of continuing improvement in design and manufacturing of its products. The right
is therefore reserved to vary specifcations without notice | Revised 06/2018
St Michel Industries Ltd, PO Box 21 122, Henderson, Auckland | Phone: 09 837 4276 | www.stmichel.co.nz
PLUMBING POSITIONS
London
Dignity, Respect, Pride & Star -
Cherry Pie Matte
London 900
Product No: 1187, 1189
100
C L
to waste
outlet
447
100
C L
to waste
outlet
900 297
Waste Outlet
London 1200
Product No: 1191, 1193
100
C L
to waste
outlet
Finished Top Surface Finished Top Surface
It is important to decide on It is important to decide on
what height you want your what height you want your
nished top surface from the nished top surface from the
oor, this will determine where oor, this will determine where
your plumbing will be your plumbing will be
positioned. positioned.
Finished top surface
597
Finished Floor Level
Finished top surface
Finished Floor Level
