Bretford CFPS Assembly Instructions

PARTS LIST
Qty Part# Description
1 CFPS 4 Outlet Electrical Unit
TOOLS REQUIRED
Phillips Screwdriver
Electric Drill (if necessary)
7/64" Drill Bit (if necessary)
OPTION 1
Lay unit down and locate pre-drilled
holes. Attach E-unit through holes
using screws (AA).
CFPS
Surge Protected Electrical Unit
Assembly Instructions
Bretford
11000 Seymour Avenue
F r a n k l i n P a r k , I L 6 0 1 3 1
TEL: 847.678.2545
800.521.9614
FAX: 847.678.0852
800.343.1779
HARDWARE LIST
Ref Qty Part#
AA 2 02112
BB 2 02236
CC 2 030-0302
Turn unit over and locate pre-drilled
holes on wood top. Attach E-unit
through holes using screws (AA).
If there are not pre-drilled holes, mark holes with a
pencil in desired location. Drill a 1/2" deep hole with
a 7/64" drill bit and attach E-unit with screws (AA).
www.bretford.com
Description
#8 x 3/8" Sheet Metal Screws
#8-32 Hex Lock Nuts
(use when necessary)
#8-32 x 3/8" Combo Truss Screws
(use when necessary)
OPTION 2
NOTE:
Part #031-1523
Rev. 04.22.08 CZ
