EXTERNAL BLINDS
PROTAL
03/2014
Updating: 07/2015
Updating: 08/2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROTAL and is the answer not in the manual?

Questions and answers

Related Manuals for Climax PROTAL

Summary of Contents for Climax PROTAL

  • Page 1 EXTERNAL BLINDS PROTAL 03/2014 Updating: 07/2015 Updating: 08/2015...
  • Page 2 1. EXTERNAL BLINDS PROTAL External Blinds PROTAL 1.1 Stack of Slats Height STACK OF SLATS BLIND HEIGHT Stack of Slats Height HEIGHT (cm) (cm) HK = HL + HP from from 50.0 145.6 25.7 75.0 171.3 25.7 145.7 162.4 26.9 171.4...
  • Page 3 1. EXTERNAL BLINDS PROTAL View from exterior Standard version Other possible versions  motor-operated version  crank - elox  self-supporting system  gear-box, bushing 45 , 90  guide rails 85 x 45 mm – anodized with installation holes ...
  • Page 4 1. EXTERNAL BLINDS PROTAL 1.6 Guide Rails and Brackets Number of installation holes HL + PVL No. of holes for mounting of blinds ≤ 130 cm 130.1 - 230 cm 230.1 - 330 cm > 330 cm Possibilities of guide rail adjustments...
  • Page 5 1. EXTERNAL BLINDS PROTAL 1.7 Mounting Holders DK 4 - Cover plate holder DK 4/5 - Cover plate holder - reinforced DK 4a - Cover plate holder - bevelled DK 4 - 200 - Cover plate holder - enlarged DK 4 - 300 - Cover plate holder - enlarged...
  • Page 6 1. EXTERNAL BLINDS PROTAL DK 5b - Cover plate holder - sliding, enlarged DK 5c - Cover plate holder - sliding, widened 100-150 100-150 101010 101010 DK 6 - Cover plate holder - sliding DK 6b - Cover plate holder - sliding, enlarged...
  • Page 7 1. EXTERNAL BLINDS PROTAL 1.7 Mounting Holders DK 567kp - Part for fixing the cover plate - shortened DK 8 - Cover plate holder - sliding 250-300 101010 DK 8b - Cover plate holder - sliding, enlarged PP - Under-plaster holder - sliding...
  • Page 8 1. EXTERNAL BLINDS PROTAL PPF 2 - Under-plaster holder - façade, sliding 190-260 PPF 3 - Under-plaster holder - façade, sliding 260-330 www.servisclimax.eu...
  • Page 9 1. EXTERNAL BLINDS PROTAL 1.8 Types of Cover Plates and Side Parts = A + B = A + B + Y = A + B + A1 KP 1 KP 2 KP 3 KP 1 = A + B...

  • Page 10: Standard Colours

    1. EXTERNAL BLINDS PROTAL 1.11 Standard Colours Standard Slat Colours NUMBER PAINT DESCRIPTION white 9003 grey 7038 silver 9006 light beige beige brown 8028 dark green 6005 azure blue 5009 780 H bronze purple red 3011 terracotta 3013 chrome yellow...

  • Page 11: Technical Documentation

    1. EXTERNAL BLINDS PROTAL 1.11 Technical Documentation Comparison of blinds with motor / crank Standard version with motor min. 60 min. 60 DL = A - 113 -8 mm Under-plaster version Version with cover plate Version with gear-box and bushing 45°...
  • Page 12 1. EXTERNAL BLINDS PROTAL 1.14 Installation of Guide Rails Installation into reveal Installation into reveal - built-in guide rails Installation via I-bracket into reveal A - blind width Installation via L-bracket into reveal and via T-bracket to connect blinds A - blind width 1 A - blind width 2 www.servisclimax.eu...
  • Page 13 1. EXTERNAL BLINDS PROTAL 1.15 Standard Placement of Gear-Box / Gear-Box Shift Limit for crank operation Adjustment of the gear-box angle for manual operation shift > + 120 mm not possible + 120 - 70 - 118 centre + 40...
  • Page 14 3. MANUAL Manual 3.1 Measuring Instructions – Blind into Window Opening Order dimensions of blind Legend: - window opening width - window opening height A - blind width HK - blind height Blind width A: Measure the inner width of the window opening (A ) at least at top, middle and bottom parts.

  • Page 15: Electric Connection

    3. MANUAL 3.2 Electric Connection 3.2.1 Building Readiness of Electric Installation 600 mm power supply 230 V~ motor 3 x 1.5 box KU 68/2 (deep) motor cable 4 x 0.75 3 x 1.5 STAS 3 terminal STAK 3 terminal box KU 68/2 (deep) 4 x 0.75 for switch external blind...

  • Page 16: Operation

    (km/h) External blinds PROTAL are constructed to withstand the wind speed up to 105 km/hour without any damage. The stated classes of wind resistance, or the wind speed, are valid for the product while pulled down and with closed slats, and provided that the wind is heading to the blind surface at a right angle with a minimum dynamic effect.
  • Page 17 Our blinds, roller shutters, awnings and insect screens improve people’s lives. They protect against the sun, ensure privacy and save energy. Places where you can buy our products www.servisclimax.eu...
  • Page 18 EXTERNAL BLINDS VENETIAN BLINDS FABRIC SHADING SYSTEMS AWNINGS EXTERNAL ROLLER SHUTTERS INSECT SCREENS PERGOLAS AND CONSERVATORIES VERTICAL FACADE AWNINGS Your partner: More information available at www.servisclimax.eu...
